第五卷 资 料 - 第13页
1-5 气路图及实际贴装图 5OM-1752 1306-002 主机 ( 实际贴装图 ) No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty 4 Solenoid V alve Unit 1 5-3 Half Union 2 7-3 Plug 2 4-1 Solenoid V alve 2 5-4 Half Union 2 4-2 Half Union 2 5-5 Half U…
1-4
气路图及实际贴装图
5OM-1752
1-41-1
1-3
1-2
2-8
2-6
2-5
2-9
2-6
2-1
2-10
2-2
2-9
3-4
3-3
3-2
3-1
3-1
3-6
3-5
3
1
2
2-4
2-7
2-3
2-11
2-11
1306-002
主机 ( 实际贴装图 )
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Air Supply Unit 1 2-5 Regulator 1 3-3 Universal Quick 3
1-1 Combination Unit 1 2-6 Regulator 2 3-4 Plug 1
1-2 Air Coupler 1 2-7 Half Union 2 3-5 Elbow Union 1
1-3 PIPE FITTING Casting Elbow 1 2-8 Half Union 1 3-6 Reducer 1
1-4 Half Union 1 2-9 Elbow Union 2
2 Air Supply Unit 1
2-10
Elbow Union 1
2-1 Vacuum Gauge 1
2-11
Elbow Union 2
2-2 Combination Unit 1 3 Vacuum Pump Unit 1
2-3 Pressure Switch 1 3-1 Vacuum Pump 1
2-4 Pressure Gauge 1 3-2 Bush 1
1-5
气路图及实际贴装图
5OM-1752
1306-002
主机 ( 实际贴装图 )
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
4 Solenoid Valve Unit 1 5-3 Half Union 2 7-3 Plug 2
4-1 Solenoid Valve 2 5-4 Half Union 2
4-2 Half Union 2 5-5 Half Union 1
4-3 Half Union 2 5-6 Half Union 1
4-4 Half Union 2 6 Manifold Unit 1
4-5 Half Union 1 6-1 Manifold 1
4-6 Half Union 1 6-2 Straight Elbow 1
5 Solenoid Valve Unit 1 7 Manifold Unit 1
5-1 Solenoid Valve 2 7-1 Manifold 1
5-2 Half Union 2 7-2 Straight Elbow 1
7-1
7-3
7-2
7
4
6-1
6-2
6
5-1
5-5
5-4
5-4
5
5-6
5-2
5-3
4-1
4-2
4-3
4-4
4-4
4-6
4-5
1-6
气路图及实际贴装图
5OM-1752
1306-002
传送带 ( 气路图 )
A
B
A
B
A
B
A
B
VBHSO
VBHSI
BHSI
BHSI
BHSO
BHSO
VBHSO
VBHSI
VBMSO
VBMSI
BMSI
BMSO
BMSI
BMSO
VBMSI
VBMSO
VBKHZ
VB3HZ
VB3HZ
B3HZ
B3HZ
VBKHZ
BKHZ
BKHZ
A
B
B3MZ
B3MZ
VB3MZ
VBKMZ
BKMZ
BKMZ
VBKMZ
VB3MZ
2
4
1
3
From Main Body
Pipe 6L1000
Pipe 6L440
Movable Side Z-Clamp L
Fixed Side Z-Clamp L
Movable Side Z-Clamp R
Fixed Side Z-Clamp R
PCB Stopper L PCB Stopper R
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
D
3.2 1
2 Tube
D
6 1
3 PIPE FITTING 1
4 Flat Tube D4.1 1
