1-16 气路图及实际贴装图 5OM-1752 1306-002 安装头部 ( 实际贴装图 ) 3 5 4 6 No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty 3 Solenoid V alve 1 4 Rotary Joint 1 5 Solenoid V alve 15 6 Filter 15
1-15
气路图及实际贴装图
5OM-1752
1306-002
安装头部 ( 气路图 )
A
V
P
R
A
P
A
V
P
A
V
P
Valve
Filter
Rotary Joint
φ8 Fitting
φ8
φ4
φ8 Fitting
φ6 Fitting
φ4 Fitting
φ4 Fitting
Valve
3
2
1
4
5
6
From Main Body
Robot Cable
Nozzle1 Nozzle2 Nozzle15
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
φ
4 1
2 Tube
φ
8 1
3 Solenoid Valve 1
4 Rotary Joint 1
5 Solenoid Valve 15
6 Filter 15
1-16
气路图及实际贴装图
5OM-1752
1306-002
安装头部 ( 实际贴装图 )
3
5
4
6
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
3 Solenoid Valve 1
4 Rotary Joint 1
5 Solenoid Valve 15
6 Filter 15
1-17
气路图及实际贴装图
5OM-1752
1306-002
送料器安装台 ( 气路图 )
5
1
2
3
4
6
From Main Body
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
φ
6 1
2 Solenoid Valve 2
3 Speed Controller 4
4 Cylinder 2
5 Modular Unit 2
6 Air Connector Pin 2
