1-20 气路图及实际贴装图 5OM-1752 NOZZLE1 NOZZLE2 7 10 12 多功能安装头部 ( 实际贴装图 ) 1306-002 No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty 7 Regulater 1 10 Solenoid V alve Unit 3 12 V acuum Filter 3
1-19
气路图及实际贴装图
5OM-1752
多功能安装头部 ( 气路图 )
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
f
6 1 11 Union Y 1
2 Tube
f
6 1 12 Manifold Unit 3
3 Tube
f
6 1 13 Solenoid Valve Unit 2
4 Tube
f
6 1 14 Vacuum Filter 2
5 Tube
f
6 2 15 Robot Cable 2
6 Tube
f
6 2
7 Tube
f
6 2
8 Tube
f
8 1
9 Tube
f
4 2
10 Regulater 1
1306-002
2
1
SETUP
0.025MPa
3
Air IN Vacuum
11
10
Nozzle 1
5
6
7
8
9
12
13
14
15
Nozzle 2
5
6
7
9
13
14
15
1-20
气路图及实际贴装图
5OM-1752
NOZZLE1
NOZZLE2
7
10
12
多功能安装头部 ( 实际贴装图 )
1306-002
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
7 Regulater 1
10 Solenoid Valve Unit 3
12 Vacuum Filter 3
1-21
气路图及实际贴装图
5OM-1752
多功能吸嘴储料器 ( 气路图 )
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
f
4 1
2 Solenoid Valve 1
3 Speed Controller 2
4 Cylinder 1
5 Cylinder 1
1306-002
4
From the Inside of Whole Base
Stocker 1 U/D Shutter 1 Open/Close
5
2
3
1
