The V ortik VPs progressive c avity pump deliv ers ow rates down to 0.28 micro liters per sec ond depending on the applic ation . The V ortik VPs with the Spectrum II S2-900 uid dispensing s ystem, and Fluidmov e softw…
Vortik VPs
Small-Volume Dispensing
Combine the Vortik VPs progressive cavity pump
with the ASYMTEK Spectrum
®
II S2-900 uid
dispensing system to support mobile electronics
and MEMS dispensing applications that require
high-precision and small volumes.
Mobile Device and
MEMs
Applications
Micro potting
Conductive epoxy
Solder paste with high volumetric accuracy
Adhesives
6 | ASYMTEK Vortik® Progressive Cavity Pump Solutions
The Vortik VPs progressive cavity pump delivers ow rates down to
0.28 microliters per second depending on the application. The Vortik VPs
with the Spectrum II S2-900 uid dispensing system, and Fluidmove software
combine to deliver high throughput, world-class precision, automated setup,
and closed-loop process control for consistent production quality.
One Component Two Component
Flow rate
VPs 2: 0.28 – 1.86 µl/s**
VPs 4: 2.66 – 24 µl/s
Flow rate*
VPs 2-2: 0.59 – 3.7 µl/s**
VPs 4-2: 4.0 – 5.6 µl/s
VPs 4-4: 5.3 – 48 µl/s
177 mm
VP
s
190 mm
*e VPs 4-2 ratio is 2:1. All other ratios are 1:1.
** e lowest volume output is dependent on the application.
ASYMTEK Vortik® Progressive Cavity Pump Solutions | 7
Package Assembly
and Automotive
Vortik VPm
Medium-Volume Dispensing
Combine the Vortik VPm progressive cavity pump with the
ASYMTEK Quantum
®
uid dispensing system to support
package assembly and automotive applications. Nordson’s
fully integrated Vortik VPm and Quantum solution provides
automated setup and closed-loop process control for high
quality results whether you’re updating an existing process or
introducing automation for the rst time.
Applications
Bonding
Sealing
Encapsulation
Potting
8 | ASYMTEK Vortik® Progressive Cavity Pump Solutions
