No. Item Code No. Specification Description Type Q’TY Remark 1 555014 - 000003 4S56Q- 02554S STEPPING MOTOR P art 1 2 V080- 520015 -B 8030 PULLEY MOTOR BKT Part 1 3 V030- 511006 -A MOTOR-PULLEY Part 1 4.5.1.6 MO T OR UNI…
4.5.1.6 MOTOR UNIT 2
1
2
3
101
No. Item Code No. Specification Description Type Q’TY Remark
1 555014-000003 4S56Q-02554S STEPPING MOTOR Part 1
2 V080-520015-B 8030 PULLEY MOTOR BKT Part 1
3 V030-511006-A MOTOR-PULLEY Part 1
4.5.1.6 MOTOR UNIT 2
102
4.5.1.7 MOTOR UNIT 3
1
2
3
103
