FILE NAME E019-0230000.VSD DATE 2010.09.14 CHANGER 8030 DUAL LANE INPUT IO MAP < 1 . 8 0 3 0 DL : I/ O M A P : I N P UT - P A R T A > NO M C S L abe l I/ O D i s c ri pt i o n 1 0 A 1 - 0 0 IN Co nv eyo r LA N E1 E…
FILE NAME E019-0230000.VSD DATE 2010.09.14 CHANGER
CN1(J7)
CN1(J7)
CN1(J7)
CN1(J7)
OUT1
OUT2
IN1
IN2
I/O Power
I/O Power
32-Channel Digital I/O
INPUT Board
32-Channel Digital I/O
OUTPUT Board
P04
P04
E019-0230300-02
E019-0230300-01
E019-0233000
E019-0234000
E019-0231000
E019-0232000
MAIN CONTROL PC
I/O & Motion Control Board
JUNCTION I/F
BOARD
I/O MODULE
DUAL I/O
INTERFACE BOARD
P
C
I
1
P
C
I
2
I/O
DC 24V
PWR
Motion Control Board CON1
Motion Control Board CON2
MOTION CABLE
IO1
AXIS/IO
POWER
EXT-I/O
J
1
J
1
0
J10
I-LUG
I-LUG
I-LUG
E019-0241400-01
To T/B03-A/B09
To T/B03-A/B04
Accept Cable
E019-0230500-01
E019-0230500-02
To T/B03-A/B03
E019-0230400-01
Extension I/O Control Board
Extension I/O Connecter
I/O OUTPUT BOARD
I/O INPUT BOARD
I-LUG
I-LUG
A1-00 : Conveyor Entry IN To FSTMC CON24
A1-03 : Conveyor Work OUT
A1-05 : Conveyor Exit OUT To FSTMC CON80
A1-06 : Work Rail UP 1
A1-07 : Work Rail UP 2
A1-11 : nSMEMA IN To FSTMC CON30
A1-10 : pSMEMA IN To FSTMC CON29
A2-00 : Conveyor Entry IN To RSTMC CON24
A2-03 : Conveyor Work OUT
A2-05 : Conveyor Exit OUT To RSTMC CON80
A2-06 : Work Rail UP 1
A2-07 : Work Rail UP 2
A2-11 : nSMEMA IN To RSTMC CON30
A2-10 : pSMEMA IN To RSTMC CON29
B1-02 : Work Stopper UP(LR) To FSTMC CON39
B1-03 : Work Stopper DOWN(LR) To FSTMC CON39
B1-09 : Work Rail UP To FSTMC CON41
B1-10 : Work Rail DOWN To FSTMC CON41
B1-11 : Height Guide CLOSE
B1-14 : pSMEMA OUT To FSTMC CON27
B1-15 : nSMEMA OUT To FSTMC CON28
B2-02 : Work Stopper UP(LR) To FSTMC CON39
B2-03 : Work Stopper DOWN(LR) To FSTMC CON39
B2-09 : Work Rail UP To FSTMC CON41
B2-10 : Work Rail DOWN To FSTMC CON41
B2-11 : Height Guide CLOSE
B2-14 : pSMEMA OUT To FSTMC CON27
B2-15 : nSMEMA OUT To FSTMC CON28
A3-00/01/03/04 : BUTTONS & EMG
B3-03/04/05/06 : TOWER LAMP
B3-00/01 : BUTTONS
B3-07 : 2D LED ON/OFF To VPC 5.1 J11
B3-08 : SERVO ENABLE To Power Realy(RL1)
J50
J54
J5
CON3
CON4
CON60
CON61
B3-22 : LANE1 NG BUFFER
B3-23 : LANE2 NG BUFFER
BUTTONS&LANE1,2 I/O
DWG.019-0235000
DWG.019-0236000
DWG.019-0236000
DWG.019-0236000
DWG.019-0236000
DWG.019-0236000
DWG.019-0236000
LANE1 SENSORS&IN-PUT
LANE2 SENSORS&IN-PUT
LANE1 CYLINDERS&OUT-PUT
LANE2 CYLINDERS&OUT-PUT
E019-0230400-02
To T/B03-A/B01
To T/B03-A/B02
EXTENSION I/O CABLE
A1-12 : Conveyor Collision
A2-12 : Conveyor Collision
A
DSG.
HO.KIM
REV.
DWG.
Y.M.LEE
SUBNET
CHK.
K.H.KIM
X
APPR.
E.H.S
MODEL
NAME
SHEET
DWG NO
KY8030 DL
I/O Control Block Diagram
1 OF 14
E019-0230000
J52
B3-10/11/12/13 : Backup Unit Sol
DWG.019-0234100
B1-04 : LANE1 Trigger
B2-04 : LANE2 Trigger
FILE NAME E019-0230000.VSD DATE 2010.09.14 CHANGER
8030 DUAL LANE INPUT IO MAP
< 1. 8030 DL : I/O MAP : INPUT-PART A>
NO MCS Label I/O Discription
1 0 A1-00 IN Conveyor LANE1 Entry IN
2 1 A1-01 IN
3 2 A1-02 IN
4 3 A1-03 IN Conveyor LANE1 Work OUT
5 4 A1-04 IN
6 5 A1-05 IN Conveyor LANE1 Exit OUT
7 6 A1-06 IN Conveyor LANE1 Backup UP 1
8 7 A1-07 IN Conveyor LANE1 Backup UP 2
9 8 A1-08 IN
10 9 A1-09 IN
11 10 A1-10 IN Conveyor LANE1 SMEMA Entry IN
12 11 A1-11 IN Conveyor LANE1 SMEMA Exit IN
13 12 A1-12 IN Conveyor LANE1 Collision
14 13 A1-13 IN
15 14 A1-14 IN
16 15 A1-15 IN
17 16 A2-00 IN Conveyor LANE2 Entry IN
18 17 A2-01 IN
19 18 A2-02 IN
20 19 A2-03 IN Conveyor LANE2 Work OUT
21 20 A2-04 IN
22 21 A2-05 IN Conveyor LANE2 Exit OUT
23 22 A2-06 IN Conveyor LANE2 Backup UP 1
24 23 A2-07 IN Conveyor LANE2 Backup UP 2
25 24 A2-08 IN
26 25 A2-09 IN
27 26 A2-10 IN Conveyor LANE2 SMEMA Entry IN
28 27 A2-11 IN Conveyor LANE2 SMEMA Exit IN
29 28 A2-12 IN Conveyor LANE2 Collision
30 29 A2-13 IN
31 30 A2-14 IN
32 31 A2-15 IN
< 2. 8030 DL : I/O MAP : INPUT-PART B >
NO MCS Label I/O Discription
1 0 A3-00 IN Button STOP
2 1 A3-01 IN Button START
3 2 A3-02 IN
4 3 A3-03 IN Button EMG
5 4 A3-04 IN Door OPEN
6 5 A3-05 IN Main Air Pressure Check
7 6 A3-06 IN
8 7 A3-07 IN
9 8 A3-08 IN
10 9 A3-09 IN
11 10 A3-10 IN
12 11 A3-11 IN
13 12 A3-12 IN
14 13 A3-13 IN
15 14 A3-14 IN
16 15 A3-15 IN
17 16 A3-16 IN
18 17 A3-17 IN
19 18 A3-18 IN
20 19 A3-19 IN
21 20 A3-20 IN
22 21 A3-21 IN
23 22 A3-22 IN
24 23 A3-23 IN
A
DSG.
HO.KIM
REV.
DWG.
Y.M.LEE
SUBNET
CHK.
K.H.KIM
X
APPR.
E.H.S
MODEL
NAME
SHEET
DWG NO
KY8030 DL
I/O MAP
2 OF 14
E019-0230100
FILE NAME E019-0230000.VSD DATE 2010.09.14 CHANGER
< 2. 8030 DL : I/O MAP : OUTPUT-PART B>
No. MCS Label I/O Discription
1 0 B3-00 OUT Button STOP Lamp
2 1 B3-01 OUT Button START Lamp
3 2 B3-02 OUT
4 3 B3-03 OUT Alarm Sound
5 4 B3-04 OUT Tower Lamp GREEN
6 5 B3-05 OUT Tower Lamp YELLOW
7 6 B3-06 OUT Tower Lamp RED
8 7 B3-07 OUT Head 2D LED
9 8 B3-08 OUT Servo Power Enable
10 9 B3-09 OUT
11 10 B3-10 OUT LANE1 Backup UP Sol
12 11 B3-11 OUT LANE1 Backup Down Sol
13 12 B3-12 OUT LANE2 Backup UP Sol
14 13 B3-13 OUT LANE2 Backup Down Sol
15 14 B3-14 OUT
16 15 B3-15 OUT
17 16 B3-16 OUT
18 17 B3-17 OUT
19 18 B3-18 OUT
20 19 B3-19 OUT
21 20 B3-20 OUT
22 21 B3-21 OUT
23 22 B3-22 OUT Conveyor LANE1 NG Buffer Machine Signal
24 23 B3-23 OUT Conveyor LANE2 NG Buffer Machine Signal
8030 DUAL LANE OUTPUT IO MAP
< 1. 8030 DL : I/O MAP : O UTPUT-PART A>
No. MCS Label I/O Discription
1 0 B1-00 OUT
2 1 B1-01 OUT
3 2 B1-02 OUT Conveyor LANE1 Work Stopper UP Sol (LR)
4 3 B1-03 OUT Conveyor LANE1 Work Stopper DOWN Sol (LR)
5 4 B1-04 OUT LANE1 Barcode Trigger
6 5 B1-05 OUT
7 6 B1-06 OUT
8 7 B1-07 OUT
9 8 B1-08 OUT
10 9 B1-09 OUT Conveyor LANE1 Backup UP Sol
11 10 B1-10 OUT Conveyor LANE1 Backup DOWN Sol
12 11 B1-11 OUT Conveyor LANE1 Height Guide CLOSE Sol
13 12 B1-12 OUT
14 13 B1-13 OUT
15 14 B1-14 OUT Conveyor LANE1 Entry SMEMA OUT
16 15 B1-15 OUT Conveyor LANE1 Exit SMEMA OUT
17 16 B2-00 OUT
18 17 B2-01 OUT
19 18 B2-02 OUT Conveyor LANE2 Work Stopper UP Sol (LR)
20 19 B2-03 OUT Conveyor LANE2 Work Stopper DOWN Sol (LR)
21 20 B2-04 OUT LANE2 Barcode Trigger
22 21 B2-05 OUT
23 22 B2-06 OUT
24 23 B2-07 OUT
25 24 B2-08 OUT
26 25 B2-09 OUT Conveyor LANE2 Backup UP Sol
27 26 B2-10 OUT Conveyor LANE2 Backup DOWN Sol
28 27 B2-11 OUT Conveyor LANE2 Height Guide CLOSE Sol
29 28 B2-12 OUT
30 29 B2-13 OUT
31 30 B2-14 OUT Conveyor LANE2 Entry SMEMA OUT
32 31 B2-15 OUT Conveyor LANE2 Exit SMEMA OUT
A
DSG.
HO.KIM
REV.
DWG.
Y.M.LEE
SUBNET
CHK.
K.H.KIM
X
APPR.
E.H.S
MODEL
NAME
SHEET
DWG NO
KY8030 DL
I/O MAP
3 OF 14
E019-0230200
