FILE NAME E019-0230000.VSD DATE 2010.09.14 CHANGER Servo Power Enable WIRE 20*1C, 1500mm LABLE : CNB113 5559 Pin Power Unit CN2 Pin2 To See DWG.E042- 0110200 No. Sig . Label Connector 1 GND 2 Signal 3 2D SW-J11 5051-03 1…

100%1 / 253
FILE NAME E019-0230000.VSD DATE 2010.09.14 CHANGER
FRONT PANEL STOP
SWITCH & LAMP RED
FRONT PANEL START
SWITCH & LAMP GREEN
Y-Lug(M4) 1.24 X 3Y
Length : 600mm
Extend : 250mm
SW
SW
3
4
G24V
START
No.
1
2
Label : J50 BUTTON
(Molex) 35155-15
ColorSig.Name
G24V
STOP
7
8
G24V
EMG
5
6
9
10
G24V
DOOR
12
13
11
14
15
To Power Unit DWG. 12000/A3 CN1 Pin 2
To Power Unit DWG. 12000/A3 CN1 Pin 1
#24 2C 2500mm
Tube Label : DOOR PWR
AWG#26,RED
AWG#26,BLU
AWG#26,BRN
No.ColorSig.Name
1+24V
2G24V
3IN17
No. Sig. Label Connector
1 +24V
2 G24V
3 Signal
A1-09
SMP-03V-NC
1400mm
Main Air Pressure
Length
No.Sig.LabelConnector
1+24V
2G24V
3Signal
A1-09
SMR-03V-N
500mm
Length
LABEL : J15 Air Pressure
(Molex) 35155-06
No. Sig. Label Connector
1 G24V
2 DOOR
3 N.C
DOOR I/O
5559-04
1300mm
Length
4 N.C
No.Sig.LabelConnector
1G24V
2DOOR
3N.C
DOOR I/O
5557-04
500mm
Length
4N.C
No. Sig.
1 G24V
2 G24V
3 G24V
4 +24V
5 +24V
6 +24V
7 G24V
8 N.C
9
10 STOP
11 START
12
13 STOP
14 START
15
16 EMG
17 N.C
18
Label Connector
BUTTON
LAMP
SMP-18V-NC
1500mm
Length
No.Sig.
1G24V
2G24V
3G24V
4+24V
5+24V
6+24V
7G24V
8N.C
9
10STOP
11START
12
13STOP
14START
15
16EMG
17N.C
18
LabelConnector
BUTTON
LAMP
SMR-18V-N
500mm
Length
AWG#26,RED
AWG#26,BLU
AWG#26,BRN
DOOR OPEN I/O
AWG#26,WHT
Emergency I/O N.O
*Same Connector
DWG.E019-0236000 BUTTON LAMP
5559Pin
A
DSG.
HO.KIM
REV.
DWG.
Y.M.LEE
SUBNET
CHK.
K.H.KIM
X
APPR.
E.H.S
MODEL
NAME
SHEET
DWG NO
KY8030 DL
Dual I/O Board INPUT Part
13 OF 14
E019-0235000
FILE NAME E019-0230000.VSD DATE 2010.09.14 CHANGER
Servo Power
Enable
WIRE 20*1C, 1500mm
LABLE : CNB113
5559 Pin
Power Unit CN2 Pin2
To See DWG.E042- 0110200
No. Sig. Label Connector
1 GND
2 Signal
3
2D SW-J11
5051-03
1300mm
VPC BOARD
No. Sig. Label Connector
1 +24V
2
3 Signal
4 Signal
5 Signal
6 Signal
LAMP
5559-06
Length
1850mm
No.Sig.LabelConnector
1+24V
2
3Alarm
4Green
5Yellow
6Red
LAMP
5557-06
Length
Tower Lamp & Alarm Sound
Manics(PRPB24-3(+COMM.))
BLK
GRAY
GRN
YEL
RED
No.
1
2
LABEL : CON3 2D LED
(Molex) 35155-02
ColorSig.Name
G24V
OUT7
3
4
GREEN
YELLOW
No.
1
2
LABEL : J5 TOWER LAMP
(Molex) 35155-05
ColorSig.Name
+24V
ALARM
5RED
No.
1
2
LABEL : CON4 SERVO ENABLE
(Molex) 35155-02
ColorSig.Name
G24V
OUT8
FRONT PANEL STOP
SWITCH & LAMP RED
FRONT PANEL START
SWITCH & LAMP GREEN
Y-Lug(M4) 1.24 X 3Y
Length : 600mm
Extend : 250mm
SW
SW
3
4
+24V
START
No.
1
2
LABEL : J54 BUTTON LAMP
(Molex) 35155-08
ColorSig.Name
+24V
STOP
7
8
5
6
To Power Unit DWG. 12000/A3 CN1 Pin 4
To Power Unit DWG. 12000/A3 CN1 Pin 3
#22 2C 1500mm
5559Pin
No. Sig.
1 G24V
2 G24V
3 G24V
4 +24V
5 +24V
6 +24V
7 G24V
8 N.C
9
10 STOP
11 START
12
13 STOP
14 START
15
16 EMG
17 N.C
18
Label Connector
BUTTON
LAMP
SMP-18V-NC
1500mm
Length
No.Sig.
1G24V
2G24V
3G24V
4+24V
5+24V
6+24V
7G24V
8N.C
9
10STOP
11START
12
13STOP
14START
15
16EMG
17N.C
18
LabelConnector
BUTTON
LAMP
SMR-18V-N
500mm
Length
Emergency I/O N.O
*Same Connector
DWG.E019-0235000 BUTTON LAMP
No.
1
2
LABEL : CON60 LN1 NG
(Molex) 35155-02
ColorSig.Name
Siganal
Siganal
From NG Buffer Signal Lane1–With Connecting FSTMC-nSMEMA
From DWG. E042-0256100-03
No.
1
2
LABEL : CON61 LN2 NG
(Molex) 35155-02
ColorSig.Name
Siganal
Siganal
From NG Buffer Signal Lane2–With Connecting RSTMC-nSMEMA
From DWG. E042-0256200-03
A
DSG.
HO.KIM
REV.
DWG.
Y.M.LEE
SUBNET
CHK.
K.H.KIM
X
APPR.
E.H.S
MODEL
NAME
SHEET
DWG NO
KY8030 DL
Dual I/O Board OUTPUT Part
14 OF 14
E019-0236000
FILE NAME E019-0230000.VSD DATE 2010.09.14 CHANGER
ASS’Y
RIGHTLEFT
LABEL
RIGHTLEFT
CONNECTOR
CABLE
LENGTH
(mm)
TYPE
Q’TY
(EA)
SERIAL
NUMBER
A I/O-INI/O-IN
DSUB 37pin MaleDSUB 37pin Male
UL,2464,#24*37C 550 1 01
B I/O-OUTI/O-OUT DSUB 25pin Male
DSUB 25pin Male
UL,2464,#24*25C 550 1 02
1
1
A
DSG.
HO.KIM
REV.
DWG.
Y.M.LEE
SUBNET
CHK.
K.H.KIM
X
APPR.
E.H.S
MODEL
NAME
SHEET
DWG NO
KY8030 DL
I/O Module Cable
6 OF 14
E019-0230500
NO
1
2
3
4
5
6
7
8
9
CASE
ColorSig.
DCD
RXD
TXD
DTR
SG
DSR
RTS
CTS
FG
NO
1
2
3
4
5
6
7
8
9
CASE
Color Sig.
DCD
RXD
TXD
DTR
SG
DSR
RTS
CTS
FG
1
D-SUB 9PIN (Female)
Hexagon nut assembling
D-SUB 9PIN
(Male)
*육각 너트 조립*
ASS„Y “A” HARNESS PIN MAPPING
ASS‘Y: “A”
1
NO
1
4
3
2
5
6
9
8
7
10
11
14
13
12
15
Color Sig.
+10-28VDC
SG
RXD(RXD-)
TXD(TXD-)
Trigger-
RTS(TXD+)
Trigger+
Default
OUT 1+
CTS(RXD+)
OUT 3+
OUT 2+
F.G
New Master
OUT 1/2/3-
NO
1
4
3
2
5
6
9
8
7
10
11
14
13
12
15
ColorSig.
+10-28VDC
SG
RXD(RXD-)
TXD(TXD-)
Trigger-
RTS(TXD+)
Trigger+
Default
OUT 1+
CTS(RXD+)
OUT 3+
OUT 2+
F.G
New Master
OUT 1/2/3-
D-SUB 3열 15PIN
(Female)
*롱 스크류 사용*
D-SUB 3열 15PIN (Male)
*육각 너트 조립*
ASS„Y “B” HARNESS PIN MAPPING
ASS‘Y: “B”
