KY8030-2XDL(2P) Part List (20120430) - 第63页
4.2 SECO ND MOVINF RAIL (REAR) 17 18 19 63
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-510003-A KY8030DL RAIL 2 Part 1 BOM확인요망
2 V085-510008-A PCB GUIDE RAIL-2 Part 1
3 V085-510006-A INLET HEIGHT GUIDE Part 1
4 602013-000038 ESD-RING-BELT-2100-DL1 RING BELT Part 1
5 A010-D53003 UP/DOWN RAIL 2 Assembly 1 4.2.1
6 V085-510007-A PCB GUIDE RAIL-1 Part 1
7 A010-D51021-A LM GUIDE BLOCK Part 2
8 602415-000019 SMALL 3D FRANGE ROLLER ROLLER Part 10
9 602415-000016 ESD D FLANGE BELT ROLLER ROLLER Part 4
10 A010-D52011-A CONNECTER BKT 1 Part 1
11 A010-D53004 2-3WORK RING BELT ASS’Y Assembly 1 4.2.2
12 554011-000005 PM-Y44 PHOTO SENSOR Part 1
13 A010-520006-C LIMIT SENSOR DOG Part 1
14 A010-D53005 TESIONER 2 Assembly 1 4.2.3
15 A010-520016-A SMALL BELT GUIDE Part 1
4.2 SECOND MOVINF RAIL (FRONT)
62
4.2 SECOND MOVINF RAIL (REAR)
17
18
19
63
No. Item Code No. Specification Description Type Q’TY Remark
17 A010-D53002 LM FIX BKT Assembly 2
18 V085-520010-A CAFLUX BKT R Part 1
19 A010-D51019 INLET HEIGHT GUIDE BLOCK Part 1
