KY8030-2XDL(2P) Part List (20120430) - 第65页
4.2.1 UP/D OWN RAIL 2 1 2 3 4 5 7 6 8 65
No. Item Code No. Specification Description Type Q’TY Remark
17 A010-D53002 LM FIX BKT Assembly 2
18 V085-520010-A CAFLUX BKT R Part 1
19 A010-D51019 INLET HEIGHT GUIDE BLOCK Part 1
4.2 SECOND MOVINF RAIL (REAR)
64
4.2.1 UP/DOWN RAIL 2
1
2
3
4
5
7
6
8
65
No. Item Code No. Specification Description Type Q’TY Remark
1 A010-D51007-A RING BELT RAIL Part 1
2 A010-D51016-A INLET CYLINDER BLOCK Part 1
3 609037-000007 URETHANE STOPPER STOPPER Part 2
4 A010-D51017-A INLET CYLINDER JOINT Part 1
5 A010-D51018-A INLET CYLINDER HOUSING Part 1
6 706012-000003 M-5AU-4 FITTING Part 2
7 701011-000014 CQ2A-16-10D CYLINDER Part 1
8 A010-D52012-A SENSOR DOG 1 Part 1
4.2.1 UP/DOWN RAIL 2
66
