4.5 MO T OR FIX BKT (F RONT) 3 1 2 4 85
4.4.1 STOPPER 2
No. Item Code No. Specification Description Type Q’TY Remark
1 V080-510056-A STOPPER TIP 20’ Part 1
2 A010-D51008-A STOPPER TIP BKT Part 1
3 602511-000001 DU0812 DU BUSH Part 4
4 A010-510021-A STOPPER BLOCK Part 1
5 A010-510023-A WORK STOPPER SHAFT Part 2
6 V080-510057-A STOPPER SHAFT BASE Part 1
7 V080-510009-B CYLINDER SHAFT JOINT Part 1
8 706011-000007 AS1201F-M3-04 SPEED CONTROL Part 2
9 701011-000017 CJP2B10-15D CYLINDER Part 1
84
4.5 MOTOR FIX BKT (FRONT)
3
1
2
4
85
4.5 MOTOR FIX BKT (FRONT)
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-520008-A CABLE MOTOR COVER Part 1
2 V085-510000 MOTOR BKT Assembly 1 4.5.1
3 V085-510100 LEFT DISTRIBUTION MODULE Assembly 1 4.5.2
4 V085-510200 RIGHT DISTRIBUTION MODULE Assembly 1 4.5.3
