Fig. Q-4 カバーテープ巻取り部 Cover T ape Winding Section 0912-002 Fig. Q テープフィーダ GT -44562 T ape Feeder GT -44562 3B4 386 3B3 3A1 3B1 3B1 3A2 3D9 3A4 3A4 3B8 3B8 3E1 3E1 331 3D4 3B0 3B9 3C0 3B7 3B6 391 3C4 394 3C3 396 397 398 399…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
266 223E0539 GEAR 1 1092600602-066
267 023S0070 ASSY_SPROCKET 1 1092600602-067
268 023S0071 ASSY_SPROCKET 1 1092600602-068
269 216D0545 PIN_HINGE 1 1092600602-069
270 222D0403 BEARING_RADIAL 1 1092600602-070
271 223L0273 BELT_TIMING 1 1092600602-071
272 216E1485 PIN_LOCATE 1 1092600602-072
273 221AA005 BOLT_HEX-SCT 2 1092600602-073
274 221AA006 BOLT_HEX-SCT 8 1092600602-074
275 221AA095 ROHS_HEX-SCT 2 1092600602-075
276 221DA202 MACHINE SCREW 2 1092600602-076
277 211F8483 BRACKET 1 1092600602-077
278 221AB002 BOLT HEX-SCT 2 1092600602-078
279 221AA106 ROHS_HEX-SCT 2 1092600602-079
280 216A1420 COLLAR 1 1092600602-080
281 221H0253 WASHER 1 1092600602-081
282 222D0144 BEARING_RADIAL 1 1092600602-082
283 222D0298 BEARING_RADIAL 2 1092600602-083
2A6 09262504 ASSY MOTOR 1 M01 1092600602-146
2A7 221HA003 WASHER 2 1092600602-147
2A8 221HA203 WASHER 2 1092600602-148
2C3 216A1359 COLLAR(BEARING) 1 3092602103-003
2C6 223Q0643 PULLEY_TIMING 1 3092602103-006
2C7 221C0100 SET SCREW 3 3092602103-007
GT-44562
Fig. Q
1011-003
Fig. Q-3
44,56mm TF
Fig. Q
GT-44562
Fig. Q-4
カバーテープ巻取り部
Cover T
ape Winding Section
0912-002
Fig. Q
テープフィーダ
GT-44562
Tape Feeder GT
-44562
3B4
386
3B3
3A1
3B1
3B1
3A2
3D9
3A4
3A4
3B8
3B8
3E1
3E1
331
3D4
3B0
3B9
3C0
3B7
3B6
391
3C4
394
3C3
396
397
398
399
3A0
3A9
384
3A3
3A5
392
3B0
3A6
3B5
389
395
3C1
3A9
393
390
387
388
3C5
3C2
385
385
3B2
3A7
3A8
See Fig.Q-1
Key No.1
44,56mm TF
Fig. Q
GT-44562
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
331 221DA003 MACHINE SCREW 2 1092600602-031
384 0926C20M BASE 1 1092600602-084
385 023E0003 ASY_GEAR(MAKU) 2 1092600602-085
386 023E0036 ASSY_GEAR(HSB) 2 1092600602-086
387 0926220G ASSY,GEAR 1 1092600500-087
388 0926220H ASSY,GEAR 1 1092600500-088
389 016S1062 ASSY LEVER 1 1092600602-089
390 211DA183 PLATE 1 1092600602-090
391 216D0470 PIN_HINGE(PVT1) 1 1092600602-091
392 221FA006 NUT_HEX 1 1092600602-092
393 211AE211 COVER(HIRA-1) 1 1092600602-093
394 211AE035 COVER(HIRA-2) 1 1092600602-094
395 0926C20N SPRING_COMP 1 1092600602-095
396 216S3043 LEVER(MAKITORI) 1 1092600602-096
397 216F0897 PIN_GUIDE 1 1092600602-097
398 213C0214 ROLLER(A) 1 1092600602-098
399 213C0255 ROLLER 1 1092600602-099
3A0 216D0471 PIN_HINGE 1 1092600602-100
3A1 222M1321 SPRING_COMP 1 1092600602-101
3A2 216F0885 PIN_GUIDE(BANE) 1 1092600602-102
3A3 4M130019 MOTOR_DC 1 1092600602-103
3A4 222D0377 BEARING_RADIAL 4 1092600602-104
3A5 216E1485 PIN_LOCATE 2 1092600602-105
3A6 216D0472 PIN_HINGE 1 1092600602-106
3A7 221AA089 ROHS_HEX-SCT 3 1092600602-107
3A8 221AA092 ROHS_HEX-SCT 2 1092600602-108
3A9 221DA060 MACHINE SCREW 3 1092600602-109
3B0 221KA002 ROHS:RING 3 1092600602-110
3B1 221KB002 E RING 2 1092600602-111
3B2 221AA099 ROHS_HEX-SCT 2 1092600602-112
3B3 023E0033 ASSY_GEAR 1 1092600602-113
3B4 223E0415 GEAR 1 1092600602-114
3B5 216D0501 PIN_HINGE 1 1092600602-115
3B6 211D9914 PLATE 1 1092600602-116
3B7 211D9915 PLATE 1 1092600602-117
3B8 221DA007 MACHINE SCREW 5 1092600602-118
3B9 211F8853 BRACKET 1 1092600602-119
3C0 221E0312 BOLT 1 1092600602-120
3C1 221DA101 MACHINE SCREW 2 1092600602-121
3C2 216A1533 COLLAR(HASUBA) 1 1092600602-122
3C3 0926C20B COVER 1 1092600602-123
3C4 216D0614 PIN_HINGE 1 1092600602-124
3C5 0926B400 SEAL 1 1092600602-125
3D4 23G10088 SENSOR_PHOTO 1 1092600602-144
3D9 216E1489 PIN_LOCATE 2 1092600602-149
