Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 102 21 1G5053 BLOCK(KIBAN) 1 1092600700-002 107 0926C00M COVER(KIBAN) 1 1092600700-007 109 016S1022 ASSY_L VR(RELAS) 1 1092600700-009 1 10 216D0448 PIN_HINGE 1 1092600700-…
Fig. T-2
操作パネル部
Operation Panel Section
1006-003
Fig. T
テープフィーダ
GT-72002
Tape Feeder GT
-72002
102
-1
1 19
138
139
153
129
11
1
1 12
134
134
127
1 13
109
1 10
123
1 18
107
125
125
138
See Fig. T
Key No.1
128
1A6
1 16
133
1 17
183
137
123
72mm TF
Fig. T
GT-72002
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
102 211G5053 BLOCK(KIBAN) 1 1092600700-002
107 0926C00M COVER(KIBAN) 1 1092600700-007
109 016S1022 ASSY_LVR(RELAS) 1 1092600700-009
110 216D0448 PIN_HINGE 1 1092600700-010
111 213C0206 ROLLER 1 1092600700-011
112 216F0879 PIN_GUIDE(ROLL) 1 1092600700-012
113 222P0207 SPRING_TORSION 1 1092600700-013
116 09262007 ASSY_GRIP 1 1092600700-016
117 211AB843 COVER(GRIP) 1 1092600700-017
118 211A8726 COVER(HAISEN) 1 1092600700-018
119 216E1741 PIN_LOCATE 2 1092600700-019
123 221DA051 MACHINE SCREW 2 1092600700-023
125 221DA103 MACHINE SCREW 5 1092600700-025
127 221AA102 ROHS_HEX-SCT 2 1092600700-027
128 221AB004 BOLT_HEX-SCT 2 1092600700-028
129 221DA113 MACHINE SCREW 1 1092600700-029
133 221DA133 MACHINE SCREW 2 1092600700-033
134 221KB001 E RING 2 1092600700-034
137 0804000D NAMEPLATE_INDEX 1 1092600700-037
138 0926B008 PLATE NOTICE 2 1092600700-038
139 0804000E NAMEPLATE_INDEX 1 1092600700-039
153 0804000M MECH PARTS 1 1092600700-053
183 4B111602 P.C.B,MOUNT 1 1092600700-133
1A6 221HA104 WASHER 2 1092600700-146
GT-72002
Fig. T
1011-004
Fig. T-2
72mm TF
Fig. T
GT-72002
Fig. T-3
テープ駆動部
Tape Driving Section
1006-003
Fig. T
テープフィーダ
GT-72002
Tape Feeder GT
-72002
2B3
266
2B4
2B7
2B7
D
268
267
265
264
263
262
269
271
272
2A8
2A9
2A7
265
269
263
D
274
270
273
See Fig.T-1
Key No.1
See Fig.T-1
Key No.40
72mm TF
Fig. T
GT-72002
