Fig. T -5 サプレッサ部 Suppressor Section 1006-003 Fig. T テープフィーダ GT -72002 T ape Feeder GT -72002 449 449 443 4B6 4B5 4B0 4A9 4B4 4B2 4B1 4B3 4B7 4B8 4B9 456 457 See Fig.T -1 Key No.1 See Fig.T -1 Key No.40 72mm TF Fig. T GT …

MEMO

Fig. T-5

サプレッサ部

Suppressor Section

1006-003

Fig. T

テープフィーダ

GT-72002

Tape Feeder GT

-72002

449

443

4B6

4B5

4B0

4A9

4B4

4B2

4B1

4B3

4B7

4B8

4B9

456

457

See Fig.T-1

Key No.1

See Fig.T-1

Key No.40

72mm TF

Fig. T

GT-72002

Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

443 211AE287 COVER(RC) 1 1092600700-043

449 221DA106 MACHINE SCREW 4 1092600700-049

456 211DE587 PLATE 1 1092600700-056

457 221D0201 MACHINE SCREW 2 1092600700-057

4A9 216S3291 LEVER(SUP) 1 1092600700-119

4B0 216D0497 PIN_HINGE(SUP) 1 1092600700-120

4B1 222P0201 SPRING_TORSION 1 1092600700-121

4B2 016J0028 ASSY_HOOK(FRNT) 1 1092600700-122

4B3 216D0467 PIN_HINGE(FRNT) 1 1092600700-123

4B4 222M1325 SPRING_COMP 1 1092600700-124

4B5 221C0027 SET SCREW 1 1092600700-125

4B6 221KB002 E RING 2 1092600700-126

4B7 0804000H NAMEPLATE 1 1092600700-127

4B8 221H0230 WASHER 1 1092600700-128

4B9 221DA103 MACHINE SCREW 1 1092600700-129
