Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1011-001
72mm TF
Fig. TD
DS-72002
3 0926200R PLATE INDEX 1 109260070A-003
4 0926200S PLATE INDEX 1 109260070A-004
5 221AA105 BOLT_HEX-SCT 2 109260070A-005
6 211DA550 PLATE 1 109260070A-006
7 221DA115 MACHINE SCREW 2 109260070A-007
11 210B4392 FRAME 1 2092600F00-001
12 0926J005 ASSY COVER 1 2092600F00-002
13 211A9111 COVER(D) 1 2092600F00-003
14 23G10090 SENSOR,PHOTO 1 2092600F00-004
15 221DA065 MACHINE SCREW 2 2092600F00-005
16 221DA103 MACHINE SCREW 4 2092600F00-006
17 221DA056 MACHINE SCREW 2 2092600F00-007
18 0926J00B GUIDE 1 2092600F00-008
