Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE Fig. X-4 1006-001 Fig. X 3C0 23G10088 SENSOR_PHOTO 1 1092600E00-130 3C3 221HA003 W ASHER 2 1092600E00-133 3C4 221HA203 W ASHER 2 1092600E00-134 3C5 216E1489 PIN_LOCA TE 2 …
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
329 221DA003 MACHINE SCREW 2 1092600E00-029
370 0926C20M BASE 1 1092600E00-070
371 023E0003 ASSY,GEAR(MAKITORI) 2 1092600E00-071
372 023E0036 ASSY,GEAR(HASUBA) 2 1092600E00-072
373 023E0028 ASSY GEAR 1 1092600E00-073
374 023E0026 ASSY GEAR 1 1092600E00-074
375 016S0953 ASSY LEVER 1 1092600E00-075
376 211DD109 PLATE 1 1092600E00-076
377 216D0579 PIN_HINGE(PVT1) 1 1092600E00-077
378 221FA006 NUT_HEX 1 1092600E00-078
379 211AC261 COVER 1 1092600E00-079
380 211AC262 COVER(HIRA-2) 1 1092600E00-080
381 222M1329 SPRING_COMP 1 1092600E00-081
382 216S3156 LEVER(MAKITORI) 1 1092600E00-082
383 216F0981 PIN_GUIDE 1 1092600E00-083
384 213C0263 ROLLER(A) 1 1092600E00-084
385 213C0264 ROLLER 1 1092600E00-085
386 216D0580 PIN_HINGE 1 1092600E00-086
387 222M1321 SPRING_COMP 1 1092600E00-087
388 216F0885 PIN_GUIDE(BANE) 1 1092600E00-088
389 4M130019 MOTOR_DC 1 1092600E00-089
390 222D0377 BEARING_RADIAL 4 1092600E00-090
391 216E1485 PIN_LOCATE 2 1092600E00-091
392 216D0581 PIN_HINGE 1 1092600E00-092
393 221AA089 ROHS_HEX-SCT 3 1092600E00-093
394 221AA092 ROHS_HEX-SCT 2 1092600E00-094
395 221DA060 MACHINE SCREW 4 1092600E00-095
396 221KA002 ROHS:RING 3 1092600E00-096
397 221KB002 E RING 2 1092600E00-097
398 221AA095 ROHS_HEX-SCT 2 1092600E00-098
399 023E0027 ASSY_GEAR 1 1092600E00-099
3A0 223E0415 GEAR 1 1092600E00-100
3A1 216D0582 PIN_HINGE 1 1092600E00-101
3A2 211D9914 PLATE 1 1092600E00-102
3A3 211D9915 PLATE 1 1092600E00-103
3A4 221DA007 MACHINE SCREW 5 1092600E00-104
3A5 211FC705 BRACKET 1 1092600E00-105
3A6 221E0431 BOLT 1 1092600E00-106
3A7 221C0100 SET SCREW 4 1092600E00-107
3A8 211E1091 PIN,LOCATE 1 1092600E00-108
3A9 221DA101 MACHINE SCREW 2 1092600E00-109
3B0 216A1533 COLLAR(HASUBA) 1 1092600E00-110
3B1 0926C210 COVER 1 1092600E00-111
3B2 0926C211 PIN_HINGE 1 1092600E00-112
3B3 0926B400 SEAL 1 1092600E00-113
GT-88002
Fig. X
1011-002
Fig. X-4
88mm TF
Fig. X
GT-88002
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. X-4
1006-001
Fig. X
3C0 23G10088 SENSOR_PHOTO 1 1092600E00-130
3C3 221HA003 WASHER 2 1092600E00-133
3C4 221HA203 WASHER 2 1092600E00-134
3C5 216E1489 PIN_LOCATE 2 1092600E00-135
GT-88002
88mm TF
Fig. X
GT-88002
MEMO
