Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 3G1 23G10088 SENSOR_PHOTO 1 1 4092601402-001 3G2 0926B401 SEAL 2 2 4092601402-002 3G3 0926B400 SEAL 1 1 4092601402-003 GT -28080 GT -28082 Fig. W -4 0912-002 Fig. W テープフィー…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
334 221DA003 MACHINE SCREW 4 4 1092600000-034
347 216E1716 PIN_LOCATE 1 1 1092600000-047
348 221C0002 SET SCREW 1 1 1092600000-048
381 221F0137 NUT,HEX 2 2 1092600000-081
382 222M1329 SPRING_COMP 2 2 1092600000-082
383 0926B20L ASSY_LEVER(L) 1 1 1092600000-083
384 0926B20M ASSY_LEVER(R) 1 1 1092600000-084
385 213C0207 ROLLER(A) 2 2 1092600000-085
386 216F0998 PIN_GUIDE 1 1 1092600000-086
387 0926B201 SPRING_COMP 2 2 1092600000-087
388 216F1000 PIN_GUIDE(BANE) 2 2 1092600000-088
389 4M130018 MOTOR,DC 2 2 M91,M92 1092600000-089
390 216E1485 PIN_LOCATE 2 2 1092600000-090
391 216E1732 PINLOCATE(PVT2) 2 2 1092600000-091
392 221AA089 ROHS_HEX-SCT 4 4 1092600000-092
393 221AA107 ROHS:BOLT,HEX-SCT 2 2 1092600000-093
394 221KB002 E RING 2 2 1092600000-094
395 221C0100 SET SCREW 1 1 1092600000-095
396 216K0159 SET COLLAR 2 2 1092600000-096
3A2 223E0516 GEAR(HIRA-2) 1 1 3092601206-002
3A3 223E0458 GEAR 1 1 3092601206-003
3A4 211AC677 COVER(MAKI-2) 1 1 3092601206-004
3A5 216E1539 PINLOCATE(SITEN-1) 2 2 3092601206-005
3A6 221DA060 MACHINE SCREW 1 1 3092601206-006
3A9 211AB091 COVER 1 1 3092601206-009
3B2 221KA002 ROHS:RING 1 1 2092601204-002
3C2 223E0516 GEAR(HIRA-2) 1 1 3092601207-002
3C3 223E0458 GEAR 1 1 3092601207-003
3C4 211AC677 COVER(MAKI-2) 1 1 3092601207-004
3C5 216E1539 PINLOCATE(SITEN-1) 2 2 3092601207-005
3C6 221DA060 MACHINE SCREW 1 1 3092601207-006
3C9 211AB090 COVER 1 1 3092601207-009
3D2 221KA002 ROHS:RING 1 1 3092601205-002
3E1 016S1019 ASSY LEVER 1 1 3016S01021-001
3E2 223E0499 GEAR(HIRA-1) 1 1 3016S01021-002
3E3 216E1731 PINLOCATE(PVT1) 1 1 3016S01021-003
3E4 211G5776 BLOCK(L) 1 1 3016S01021-004
3E5 221DA103 MACHINE SCREW 1 1 3016S01021-005
3E6 221DA008 MACHINE SCREW 2 2 3016S01021-006
3F1 016S1018 ASSY LEVER 1 1 3016S01020-002
3F2 223E0499 GEAR(HIRA-1) 1 1 3016S01020-002
3F3 216E1731 PINLOCATE(PVT1) 1 1 3016S01020-003
3F4 211G5777 BLOCK(R) 1 1 3016S01020-004
3F5 221DA103 MACHINE SCREW 1 1 3016S01020-005
3F6 221DA008 MACHINE SCREW 2 2 3016S01020-006
Fig. W
1011-004
Fig. W-4
GT-28080
GT-28082
8mm TF
Fig. W
GT-28080
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
3G1 23G10088 SENSOR_PHOTO 1 1 4092601402-001
3G2 0926B401 SEAL 2 2 4092601402-002
3G3 0926B400 SEAL 1 1 4092601402-003
GT-28080
GT-28082
Fig. W-4
0912-002
Fig. W
テープフィーダ
Tape Feeder GT
-28080,28082
8mm TF
Fig. W
GT-28080
