Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 3 0804000N PLA TE INDEX 1 1092600003-003 4 0804000P PLA TE INDEX 1 1092600003-004 5 221A0098 BOL T_HEX-SCT 2 1092600003-005 1 1 0926J000 FRAME 1 2092600801-001 12 016S0729…
Fig. WD-1
継ぎ目検出ユニット
Joint Detection Unit
1006-003
Fig. WD
継ぎ目検出ユニット
DS-28080
Joint Detection Unit DS-28080
18
15
13
1
1
17
16
12
14
19
3
4
5
8mm TF
Fig. WD
DS-28080
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
3 0804000N PLATE INDEX 1 1092600003-003
4 0804000P PLATE INDEX 1 1092600003-004
5 221A0098 BOLT_HEX-SCT 2 1092600003-005
11 0926J000 FRAME 1 2092600801-001
12 016S0729 ASSY LEVER 1 2092600801-002
13 211A8923 COVER 1 2092600801-003
14 222P0183 SPRING TORSION 1 2092600801-004
15 221KB002 E RING 1 2092600801-005
16 23G10090 SENSOR,PHOTO 2 2092600801-006
17 221DA065 MACHINE SCREW 4 2092600801-007
18 221DA103 MACHINE SCREW 2 2092600801-008
19 212A2269 GUIDE 1 2092600801-009
DS-28080
Fig. WD
1006-003
Fig. WD-1
8mm TF
Fig. WD
DS-28080
