P-313-004e.pdf - 第70页

Fig. G-5 サプレッサ部 Suppressor Section 101 1-003 Fig. G テープフィーダ GT -12162 T ape Feeder GT -12162 442 495 494 487 493 4A5 4A4 4A4 489 4A6 495 4A5 494 4A2 445 493 498 491 497 492 496 446 490 488 4A3 4A3 499 4A0 See Fig.G-1 Key…

Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

331 221DA003 MACHINE SCREW 2 1092600400-031

360 0926C20L BASE(GEAR) 1 1092600400-060

361 023E0003 ASY_GEAR(MAKU) 1 1092600400-061

362 223E0425 GEAR(HASUBA) 1 1092600400-062

363 0926C205 GEAR(HIRA-1) 1 1092600400-063

364 0926220R ASSY GEAR 1 1092600400-064

365 216S2660 LEVER(KAIJYO) 1 1092600400-065

366 216E1557 PINLOCATE(PVT1) 2 1092600400-066

367 221FA006 NUT_HEX 1 1092600400-067

368 0926C207 COVER(HIRA-1) 1 1092600400-068

369 0926C208 COVER(HIRA-2) 1 1092600400-069

370 0926C20P SPRING COMP 1 1092600400-070

371 016S0967 ASSY LEVER 1 1092600400-071

372 213C0209 ROLLER(A) 1 1092600400-072

373 216F0888 PIN_GUIDE 1 1092600400-073

374 222M1311 SPRING_COMP 1 1092600400-074

375 216F0885 PIN_GUIDE(BANE) 1 1092600400-075

376 4M130018 MOTOR,DC 1 1092600400-076

377 222D0377 BEARING_RADIAL 2 1092600400-077

378 216E1485 PIN_LOCATE 2 1092600400-078

379 216E1495 PIN LOCATE 1 1092600400-079

380 221AA089 ROHS_HEX-SCT 2 1092600400-080

381 221AA092 ROHS_HEX-SCT 2 1092600400-081

382 221DA060 MACHINE SCREW 2 1092600400-082

383 221KA002 ROHS:RING 1 1092600400-083

384 211AD925 COVER 1 1092600400-084

385 216E1761 PINLOCATE(PVT1) 1 1092600400-085

386 0926B400 SEAL 1 1092600400-086

3A2 23G10088 SENSOR_PHOTO 1 1092600400-112

GT-12162

1011-003

Fig. G-4

Fig. G

12,16mm TF

Fig. G

GT-12162

Fig. G-5

サプレッサ部

Suppressor Section

1011-003

Fig. G

テープフィーダ

GT-12162

Tape Feeder GT

-12162

442

495

494

487

493

4A5

4A4

489

4A6

495

4A5

494

4A2

445

493

498

491

497

492

496

446

490

488

4A3

499

4A0

See Fig.G-1

Key No.1

For 16mm

No Used

12,16mm TF

Fig. G

GT-12162

Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

442 221J0066 SPRING_PIN 1 1092600400-042

445 211DE587 PLATE 1 1092600400-045

446 221D0201 MACHINE SCREW 2 1092600400-046

487 216S3288 LEVER(SUP) 1 1092600400-087

488 216F0913 PIN_GUIDE(SUP) 1 1092600400-088

489 222P0201 SPRING_TORSION 1 1092600400-089

490 016J0025 ASSY_HOOK(FRNT) 1 1092600400-090

491 216D0466 PIN_HINGE(FRNT) 1 1092600400-091

492 222M1491 SPRING_COMP 1 1092600400-092

493 212B2299 CHUTE 1 1092600400-093

494 09262306 ASSY,PLATE(SUP) 1 1092600400-094

495 221D0196 MACHINE SCREW 2 1092600400-095

496 221KB002 E RING 2 1092600400-096

497 221C0027 SET SCREW 1 1092600400-097

498 0804000L NAMEPLATE 1 1092600400-098

499 221H0230 WASHER 1 1092600400-099

4A0 221DA103 MACHINE SCREW 1 1092600400-100

4A2 211DE598 PLATE 1 1092600400-102

4A3 09262301 ASSY_SPRING_FL 1 1092600400-103

4A4 221DB001 MACHINE SCREW 1 1092600400-104

4A5 221DA103 MACHINE SCREW 3 1092600400-105

4A6 221DA005 MACHINE SCREW 2 1092600400-106

GT-12162

1011-003

Fig. G-5

Fig. G

12,16mm TF

Fig. G

GT-12162
