KJH_YS88_PL - 第49页
5 1 1 Non T ape Cutter (Old Type) T ape Cutter KJH-1 103 3 3 2 9 9 13 14 15 17 16 288 TYPE 384 TYPE 3 3 13 1 9 8 8 4 4 4 5 6 7 10 1 1 12 8 19 20 9 9 9 9 4 4 4 14 15 21 22 7 1 1 8 10 17 18 18 9 No. Part No. Part Name Q&ap…
4
11
Tape Cutter 24 (288) -2
Tape Cutter
KJH-090615
29
30
48
48
29
43
31
43
44
44
38
50
55
41
46
34
35
9
15
30
43
11
49
21
43
20
17
37
33
33
14
24
23
40
39
10
39
18
35
54
37
22
19
5
43
32
37
37
37
6
47
3
7
37
37
8
45
52
28
25 42
46
4
2
34
36
12
26
36
13 36
54
40
28
52
16
27
37
53
51
43
40
1
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M3T01-04 BASE PLATE 1, 288 1
2 KHY-M3T02-00 BASE PLATE 2, 288 1
3
KHY-M3T05-01 CUTTER UPPER, 288 1 OK MF50145-2009/5/29
KHY-M3T05-00 CUTTER UPPER, 288 1
4 KHY-M3T06-03 BASE PLATE 3, 288 1
5
KHY-M3T07-A2 CUTTER LOWER, 288 1 OK MF50157-2009/5/29
KHY-M3T07-A1 CUTTER LOWER, 288 1 OK MF70106-2008/7/22
KHY-M3T07-A0 CUTTER LOWER, 288 1
6 KHY-M3T08-01 BAR, L 1
7 KHY-M3T08-11 BAR, R 1
8 KHY-M3T09-02 PLATE 4, 288 1
9 KHY-M3T0A-01 SIDE BLOCK, L 1
10 KHY-M3T0A-11 SIDE BLOCK, R 1
11 KJJ-M3T0B-10 FRONT STAY, 288 S-ATS 1
12 KHY-M3T0H-00 CYL. COVER, L 1
13 KHY-M3T0H-10 CYL. COVER, R 1
14
KHY-M3T0L-01 CYL. COLLAR, 3 1 OK MF30061-2009/3/13
KHY-M3T0L-00 CYL. COLLAR, 3 1
15 KHY-M3T0M-00 STAY, COVER M 1
16 KHY-M3T0N-00 COVER M 1
17 KHY-M3T0P-00 CYL. COVER 1 1
18 KHY-M3T0U-00 SENSOR STAY 1
19 KHY-M3T0V-00 DOG., SENSOR 1
20
KHY-M3T10-01 TAPE CUTTER CYL. 1 OK MF30039-2009/3/9
KHY-M3T10-00 TAPE CUTTER CYL. 1
21 KHY-M3T11-01 CYL. STAY 1
22 KHY-M3T12-01 CLY. BLOCK 1
23 KHY-M3T13-00 CYL. COLLAR 1 1
24
KHY-M3T14-01 CYL. COLLAR 2 1 OK MF30099-2009/3/19
KHY-M3T14-00 CYL. COLLAR 2 1
25 KJJ-M3T16-10 BACK STAY, S-ATS 1
26 KHY-M3T18-00 COVER L, 288 1
27 KHY-M3T18-10 COVER R, 288 1
28 KHY-M3T19-00 SIDE COVER 2
29 KHY-M3T22-00 SHOCK ABSORBERS 2
30 KHY-M3T23-00 DAMPER STAY 2
31 KHY-M3T24-00 DAMPER STOPPER 1
32 KHY-M3T26-00 CUTTER COVER, 288 1
33 $TL4-02 JOINT 2
34 90K73-7L0130 LM RAIL 2
35 90K80-025L00 LM BLOCK, HSR25-L 2
36 91312-04006 BOLT HEX. SOCKET HEAD 7
37 91312-04008 BOLT HEX. SOCKET HEAD 20
38 91312-04010 BOLT HEX. SOCKET HEAD 2
39 91312-04016 BOLT HEX. SOCKET HEAD 2
40 91312-04018 BOLT HEX. SOCKET HEAD 12
41 91312-05010 BOLT HEX. SOCKET HEAD 6
42 91312-05018 BOLT HEX. SOCKET HEAD 4
43 91312-06014 BOLT HEX. SOCKET HEAD 18
44 91312-06016 BOLT HEX. SOCKET HEAD 6
45 91312-06020 BOLT HEX. SOCKET HEAD 5
46 91312-06022 BOLT HEX. SOCKET HEAD 4
47 91312-06025 BOLT HEX. SOCKET HEAD 3
48 91312-06030 BOLT HEX. SOCKET HEAD 4
49 91312-08020 BOLT HEX. SOCKET HEAD 4
50 92902-04600 WASHER, PLAIN 2
51 92B12-10035 SCREW, H. S. COUN. 1
52 98702-03006 SCREW, FLAT HEAD 4
53 98902-03008 SCREW, BINDING HEAD 2
54 98902-04008 SCREW, BINDING HEAD 6
55 99480-04010 PIN, PARALLEL 4
5
11
Non Tape Cutter (Old Type)
Tape Cutter
KJH-1103
3
3
2
9
9
13
14
15
17
16
288 TYPE 384 TYPE
3
3
13
1
9
8
8
4
4
4
5
6
7
10
11
12
8
19
20
9
9
9
9
4
4
4
14
15
21
22
7
11
8
10
17
18
18
9
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KJJ-M11C1-12 DUCT 1, 288 S-ATS 1 OK MF30155-2009/3/26
KJJ-M11C1-11 DUCT 1, 288 S-ATS 1 S-ATS
2 KJJ-M11C2-10 DUCT 2, 288 1 288
3
KJJ-M11C3-01 BRKT. 384, DUCT 1 2 NG MEX0004-2008/11/6
KJJ-M11C3-00 BRKT. 384, DUCT 1 2
4 KHY-M11C5-00 WASHER 6
5 KHY-M3T0E-21 UPPER COVER 1, 288 1 288
6 KHY-M3T0S-01 UPPER COVER 2, 288 1 288
7 90K41-000240 SEAL DON'T TOUCH 1
8 91312-04006 BOLT HEX. SOCKET HEAD 6
9 91312-05008 BOLT HEX. SOCKET HEAD 8
10 91312-06010 BOLT HEX. SOCKET HEAD 3
11 92902-04600 WASHER, PLAIN 4
12 92902-06600 WASHER, PLAIN 2
13 98902-04006 SCREW, BINDING HEAD 3
14 KJJ-M1325-00 COVER 25 2
15 90990-12J004 SCREW, BIN. HEAD W/W 6
16 KJJ-M3T00-G0 SLOPE ASSY, 288 1 288
17 KJJ-M3T00-L0 SAFETY COVER ASSY, N 1
18 KJJ-M3T00-E0 SLOPE ASSY, 384 2 384
19
KJJ-M11C1-02 DUCT 1, 384 1 OK MF30155-2009/3/26
KJJ-M11C1-01 DUCT 1, 384 1 384
20 KJJ-M11C2-00 DUCT 2, 384 1 384
21 KJJ-M3T0E-10 UPPER COVER 1, 384 1 384
22 KJJ-M3T0S-01 UPPER COVER 2, 384 1 384
6
11
Non Tape Cutter (New Type)
Tape Cutter
KJH-1103
15
16
10
11
16
12
20
20
20
20
9
18
20
20
20
20
14
17
13
288 TYPE
SMEMA
16
16
20
1
2
3
20
20
10
9
11
18
19
19
6
20
20
20
20
5
17
7,8
4
384 TYPE
FIX
20
21
22,23
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M3T52-00 FES STAY, L 1 FES
2 KHY-M3T52-10 FES STAY, R 1 FES
3 KJJ-M3T51-00 UPPER COVER 2,384 1
4 KJJ-M3U01-00 UPPER COVER 1,384 1
5 KJJ-M3U02-00 SLOPE COVER ,384 1
6 KJJ-M3U03-00 BASE COVER 1 FES
7 KJJ-M3U04-00 UNDER COVER, 384 2 S.T.D
8 KJJ-M3U04-10 UNDER COVER, 384 2 SMEMA
9 90K41-000240 SEAL DON'T TOUCH 2
10 KHY-M3T52-20 FIX STAY, L 2 FIX
11 KHY-M3T52-30 FIX STAY, R 2 FIX
12 KHY-M3T51-00 UPPER COVER 2,288 1
13 KJJ-M3U01-20 UPPER COVER 1,288 1
14 KJJ-M3U02-20 SLOPE COVER ,288 1
15 KJJ-M3U04-20 UNDER COVER, 288 1 SMEMA
16 91312-04006 BOLT HEX. SOCKET HEAD 6
17 91312-05008 BOLT HEX. SOCKET HEAD 6
18 91312-06010 BOLT HEX. SOCKET HEAD 6
19 98902-03006 SCREW BINDING HEAD 4
20 98902-04006 SCREW BINDING HEAD 34
21 KJJ-M3U00-20 SLOPE ASSY, 288(FIX) 1 288(FIX)
22 KJJ-M3U00-00 SLOPE ASSY, 384(FES) 1 384(FES)
23 KJJ-M3U00-10 SLOPE ASSY, 384(FIX) 1 384(FIX)
