MFU CLAMP(PQ)
MFU クランプ(PQ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No.
Drg.No. & Code No.
QTY Description Rating Materials Remarks
1 DEPQ3010 2 GUIDE ｶﾞｲﾄﾞ FE
2 H5326A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X25L FE
3 W1024A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
4 W1045A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
5 DEPQ3025 1 BKT BKT FE
6 H5371A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M10X80L FE
7 W1015A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-10-H FE
8 N4047A 3
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M6X10L FE
9 DEPQ3035 1 BKT BKT FE
10 H5371A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M10X80L FE
11 W1015A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-10-H FE
12 N4047A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M6X10L FE
13 DEPQ3042 2 BKT ＢＫＴ FE
14 H5343A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M8X30L FE
15 W1014A 8
WASHER, CONICAL
ﾜｯｼｬ 皿
M-8-H FE
16 DEPQ3050 2 STOPPER ｽﾄｯﾊﾟ PL
17 H5289A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12 FE
18 W1022A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
19 W1041A 4 WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4) FE
20 DEPQ3230 2 LEVER ﾚﾊﾞｰ FE
21 DEPQ3070 2 SHAFT ｼｬﾌﾄ FE
22 DEPQ3080 2 KNUCKLE ﾅｯｸﾙ FE
23 H5359A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M10X20L FE
24 W1015A 2
WASHER, CONICAL
ﾜｯｼｬ 皿
M-10-H FE
25 DEPQ3090 2 PIN ﾋﾟﾝ FE
26 DEPQ3300 1 GUIDE ｶﾞｲﾄﾞ FE
27 H5322A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
28 W1013A 2
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
29 DEPQ3310 1 GUIDE ｶﾞｲﾄﾞ FE
30 H5322A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
31 W1013A 2
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
32 DEPQ3110 2 GUIDE ｶﾞｲﾄﾞ FE
33 H5322A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
34 W1013A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
35 DEPQ3120 2 GUIDE ｶﾞｲﾄﾞ FE
36 H5322A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
37 W1013A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
38 DEPQ3130 1 BKT BKT FE
58
MFU CLAMP(PQ)
MFU クランプ(PQ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No.
Drg.No. & Code No.
QTY Description Rating Materials Remarks
39 H5300A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X15 HRC34-44 FE
40 W1012A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
41 DEPQ3140 2 BLOCK, LOCATING ﾌﾞﾛｯｸ 位置決め FE
42 H5324A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X20L FE
43 W1013A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
44 DEPQ3150 1 PIN, LOCATING ﾋﾟﾝ 位置決め FE
45 H5322A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
46 W1024A 1
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
47 DEPQ3160 1 PIN, LOCATING ﾋﾟﾝ 位置決め FE
48 H5322A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
49 W1024A 1
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
50 DEPQ3172 1 BKT BKT FE
51 H5288A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
52 W1011A 2
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
53 DEPQ3180 1 COVER ｶﾊﾞｰ FE
54 K5208A 2 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6 FE
55 DEPQ3190 1 COVER ｶﾊﾞｰ FE
56 K5208A 2 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6 FE
57 DEPQ1220 2 BKT, SENSOR BKT ｾﾝｻ FE
58 H5274A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6 FE
59 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
60 W1042A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
61 DEPQ1230 2 BKT, SENSOR BKT ｾﾝｻ FE
62 H5274A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6 FE
63 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
64 W1042A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
65 DEPQ3220 1 SEAL ｼｰﾙ PL
66 DＮPQ3160 1 BKT ＢＫＴ FE
66.1 DＮPQ3170 1 BKT ＢＫＴ FE
67 H5321A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X12L FE
68 H5322A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
69 W1024A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
70 W1045A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
71 DEPQ3281 1 BKT BKT FE
72 H5322A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
73 W1024A 1
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
74 DEPQ3291 1 BKT BKT FE
75 H5322A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
59
MFU CLAMP(PQ)
MFU クランプ(PQ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No.
Drg.No. & Code No.
QTY Description Rating Materials Remarks
76 W1024A 1
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
77 H2095R 1 PIN, PARALLEL ﾋﾟﾝ 平行 8ﾟX25 Bｼｭ FE
78 H30105 2 FIBER UNIT ﾌｧｲﾊﾞﾕﾆｯﾄ HPF-T003 OT
79 KPA2240 4 COLLAR ｶﾗｰ FE
80 EM42301 2 WASHER ﾜｯｼｬ FE
81 S20975 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDLQB50-30D-B-F9NL OT
82 H5337H 8 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X110L FE
83 W1013A 8
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
84 S1026A 4
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-8 FE
85 DNPQ3120 1 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ CRVA-0008W OT
86 H5294A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X30L FE
87 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
88 K1120T 4 CAM FOLLOWER ｶﾑﾌｫﾛｱ CF10-1V-A OT
89 DEPQ3321 2 STOPPER ｽﾄｯﾊﾟ PL
90 H5289A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12 FE
91 W1022A 2 WASHER, LOCK
ワッシャ スプリング
4M/M FE
92 ADEPQ8023 1 DUCT ダクト OT
93 DEPQ3340 2 BKT BKT FE
94 H5289A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12 FE
95 W1022A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
96 W1043A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
102 BHPP1880 2 RAIL ﾚｰﾙ OT
103 K5207A 4
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M4X5 FE
104 A5043T 4
RETAINER, RAIL
押え ﾚｰﾙ PFP-M OT
105 A1068C 4 AMPLIFIER, SENSOR ｱﾝﾌﾟ ｾﾝｻ HPX-NT1 OT
106 A10130 2
ATTACHMENT
ｱﾀｯﾁﾒﾝﾄ FE-PA-S1 OT
107 DEPQ3242 1 BKT, SUPPORT BKT 支え FE
108 H5323A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M06X018 FE
109 W1024A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
110 W1045A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
111 DEPQ3252 1 BKT, SUPPORT BKT 支え FE
112 H5323A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M06X018 FE
113 W1024A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
114 W1045A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
