Placement of 0402 components Manual S-20/S-23 HM/S-25 HM/F4/F5 HM/HS-50
03/2001 edition
74
10.4 Recommended pad layout
Å Reduce the size of the stencil aperture by 0.03 mm.
Å Increase the size of the solder resist by 0.05 mm.
Component A B C
0402 0.40 0.61 0.59
Standard 0402 0.43 0.45 0.51
Mini 0402 0.43 0.44 0.51
