RAPID TRANSIT CONVEYOR (RTC) MODULE
ADJUSTMENTS AND SETTINGS
22.14 Technical Reference Manual Chapter Issue 4, Aug 14
Camera X Axis Parallelism
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
WARNING
STRONG MAGNET FIELD. A STRONG MAGNETIC FIELD EXISTS IN THE
VICINITY OF THIS LABEL. THIS MAY PRESENT A HAZARD TO PERSONNEL OR
EQUIPMENT.
))
((
PROHIBITION
ELECTROMAGNETIC FIELD. AN ELECTROMAGNETIC FIELD EXISTS WITHIN
THE MACHINE FROM THE LINEAR MOTORS. THESE MAY PRESENT A HAZARD
TO PEOPLE FITTED WITH AN IMPLANTED CARDIAC DEVICE. THE MOTOR
MANUFACTURER RECOMMENDS A SAFE DISTANCE OF AT LEAST 15MM.
PROHIBITION
ELECTROMAGNETIC FIELD. AN ELECTROMAGNETIC FIELD EXISTS WITHIN
THE MACHINE FROM THE LINEAR MOTORS. THESE MAY PRESENT A HAZARD
TO PEOPLE FITTED WITH AN IMPLANTED CARDIAC DEVICE. THE MOTOR
MANUFACTURER RECOMMENDS A SAFE DISTANCE OF AT LEAST 15MM.
PROHIBITION
STRONG MAGNETIC FIELD. A STRONG MAGNETIC FIELD EXISTS IN THE
VICINITY OF THE LINEAR MOTORS THAT REPRESENT A SERIOUS HAZARD TO
PEOPLE FITTED WITH METALLIC IMPLANTS.
PROHIBITION
STRONG MAGNETIC FIELD. A STRONG MAGNETIC FIELD EXISTS IN THE
VICINITY OF THE LINEAR MOTORS THAT MAY ACT UPON FERROUS OBJECTS
WHOSE MOVEMENTS COULD LEAD TO PERSONAL INJURY AND/OR DAMAGE
TO THE MACHINE.
NOTE
The camera X axis parallelism is factory set and shouldn’t normally need to be
adjusted.
1. To move the vanes clear of the front print station rails, set the board length
to maximum and home the rapid transit conveyor board loader.
2. Home the RTC rails and set the rising table to vision height.
RAPID TRANSIT CONVEYOR (RTC) MODULE
ADJUSTMENTS AND SETTINGS
Chapter Issue 4, Aug 14 Technical Reference Manual 22.15
3. Fit the rail setting jig to the manual tooling plate locating the two dowels in
to the holes on the tooling plate.
NOTE
The rail setting jig must not exert any force on the front rail during placement.
If any force is felt, remove the jig and go to the Front Rail Parallelism section.
4. Manually pull the camera beam until the bearing guide on the camera beam
gently abuts the two camera beam stops on the rail setting jig.
5. Using a 0.05mm feeler as a NO-GO gauge, check that no gap exists
between the stops and the camera beam.
6. If adjustment is not required, manually move the camera beam away from
the jig and remove the jig from the rising table.
7. If adjustment is required, refer to the X Axis Parallelism - Adjustments and
Settings section in the Camera System Module chapter.
Board Support Plate
Rail Setting Jig
Locating Dowel
(in 2 positions)
Camera Beam Stops
RAPID TRANSIT CONVEYOR (RTC) MODULE
ADJUSTMENTS AND SETTINGS
22.16 Technical Reference Manual Chapter Issue 4, Aug 14
Rail to Table Height The rail to table height is factory set and must not be adjusted.
Board Clamp Setting
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
1. Raise the rising table to vision height.
2. Toggle the board clamps to On.
3. Using a 0.6mm feeler gauge, check that the gap between the board clamp
and the board support plate on both ends of the front print station rail.
4. Using a 0.6mm feeler gauge, check that the gap between the board clamp
and the board support plate on both ends of the rear print station rail.
5. If no adjustment is required, go to Step 10.
6. To adjust the board clamp setting, loosen the two board clamp adjustment
screws using a flat bladed screwdriver.
7. Using feeler gauges, move the board clamp to achieve the 0.6mm gap
between the board clamp and the board support plate on both ends of the
print station rail.
8. Tighten the two board clamp adjustment screws.
Board Support Plate
Feeler Gauge
Board Clamp
View on Inside of Print Station Rail
Plan View of Print Station Rail
Board Clamp
Adjustment Screw
Board Clamp
Adjustment Screw
