Head Module
4-7
NO. LEVEL
PART NO. PART NAME Q’TY
TYPE Old No.
Stock
Apply Reference
62 J70551417A BELT_IDLER_SPACER 1
63 J70551418A LOCK_NUT_Z 1
64 J70551419A LOCK_NUT_Z_2 1
65 J70551420A IDLER_HOUSING_SPACER 1
66 J70551451A BELT_BRACKET_R 1
67 J70551450A BELT_BRACKET_L 1
68 J70551424A MOTOR_BD_BKT 1
69 J70551430A R_SENSOR_BKT 1
70 J70551431A PIN_EL 2
71 J70551432A EL_TENSION_SPRING 2
72 J70551433A SPRING_BRACKET 1
73 J70551434A THETA_MOTOR_PLATE 1
74 J70551435A EL_SCREW_SPACER 1
75 J70551436A MIRROR_SPACER 1
76 J70551437A MIRROR_CAP 1
77 J70551455A BOLT_STOPPER 8
78 J70551458A FRONT_COVER 1
79 J71551296A PULLEY_Z_MOTOR 1
80 J71551297A SPINDLE_TOP_HOUSING 1
81 J71551299A SPINDLE_THETA_PULLEY 1
82 J71551300A Z_CAP 1
83 J71551301A SPINDLE_HOUSING_CAP 1
84 J71551316A MIRROR_FRAME 1
85 J71551326A CAMERA_COVER 1
86 J63091016A Y_PACKING 1
87 J66121027A COUPLING 1
88 J66011102A BEARING 3
89 J66011098A BEARING 2
90 J66011097A BEARING 2
91 J6061301000 DOWEL PIN 4
92 J6103003A HEX SUPPORT 4
Samsung Component Placer SM431 Service Manual
4-8
NO. LEVEL
PART NO. PART NAME Q’TY
TYPE Old No.
Stock
Apply Reference
93 J71551343A FLAT_TUBE_CLAMP 1
94 J70551456A FLAT_CABLE_CLAMP_1 1
95 J70551457A FLAT_CABLE_CLAMP_2 1
96 J31081030A SERVO_MOTOR 1
97 J67081010A ATMOSPHERIC_FILTER 1
98 J90551228A Z_BALL_SPLINE_ASSY_M 1
99 J66021088A TIMING_BELT 1
100 J67111068A BARB_FITTING 1
101 J7155541A PIN_Z 1
102 J7455026A SPRING BUSH 2
103 J70551452A Z_SPACER 1
104 J70551422A TENSION_SPRING 1
105 J71591093A SPACER1_M 1
106 J90591053A FLYING_LENS_ASSY_M 1
107 J67511010A CCD_MEGA_CAMERA 1
108 J71591088A MOUNT_M 1
109 J90551236A SM431_HEAD_PNEUMATIC_MODULE_ASSY 1
110 J91741192A VACUUM_SENSOR_BOARD 1
111 J66071066A LM_GUIDE 8 SEBS5BYUU1_86P
112 J66111001A Z_BALL_SPLINE_ASSY 1 WSP5-H125CM/A
113 J91741188A SM431_HEAD_IF_BOARD 1
114 J90551232A SM431_MOVING_HEAD_ASSY 1
115 J67111068A BARB_FITTING 1 M-3ALU-4
116 J91661028A FLYING_OUTER_PCB_A_ASSY 1
117 J90551235A SM431_FLYING_ILLUMINATION_ASSY 1
118 J91661029A FLYING_OUTER_PCB_B_ASSY 1
119 J66061027A BALL_SCREW 1 W1000P_3SS_C5T510
120 J61071081A TENSION-SPRING 2 AWU6-35
121 J91741193A MEGA_CAMERA_IO_BOARD 1 J91741193A
122 J90833075A FLY_CAM_SIG_EXT_CABLE_ASSY 1 SM431-VIS003
123 J67131004A AIR_TUBE 4.2
TU0425C
Head Module
4-9
NO. LEVEL
PART NO. PART NAME Q’TY
TYPE Old No.
Stock
Apply Reference
124 J67111068A BARB_FITTING 1 M-3ALU-4
125 J90833026A Z, R HOME SENSOR CABLE ASSY 1 SM431_HD009
126 J90832963A EL_HOME_SENSOR_CABLE_ASSY 1 SM431_HD003
127 J66071067A LM_GUIDE 2 SEBS7BYUU2_150P/W2
128 J6719025A HEAD_PULLS 1
129 J91741188A SM431_HEAD_IF_BOARD 1
130 J71551356A B_SOL_BKT 1
131 J73541014A FLAT_CABLE_PAD 1
132 J73541011A X_CABLE_CUSHION 1
133 J70541289A X_CABLE_FIX_BKT 1
134 J70541282A CABLE_FIX_COVER 1
135 J70541281A CABLE_FIX_BKT 1
136 J70541280A PCB_BASE_RIGHT 1
137 J70541279A PCB_BASE_LEFT 1
138 J70541278A GREASE_BKT_RIGHT 1
139 J70541277A GREASE_BKT_LEFT 1
140 J70541276A HEAD_MAIN_FRAME 1
141 J70541275A HEAD_REAR_COVER 1
142 J70541273A CONNECTOR_BKT 1
143 J70541264A X_CABLE_CUSHION_BKT 1
144 J6702037A VALVE SOLENOID 4 WAY, 24VAC.ALU 1 44B-BAA-GDFC-1BA
145 J6702049A SOLENOID VALVE 1 RCS242-M3-D24NP
146 J72601002A FLYING_OUTER_INSULATION 2
147 J72601003A FLYING_COAXIAL_INSULATION 1
148 J66011110A MINATURE_BEARING 1 MF104BZZ
