Conveyor & BUT 5-9 NO. LEVEL P ART NO. P ART NAME Q'TY TYPE Old No. Stock Apply Reference 62 J70531387A PCB_GUIDE_EDGE_05T_R 1 63 J70531388A SHUTTLE_BEL T_UNDER_GUIDE 4 64 J70531389A PCB_GUIDE_EDGE_3_2T 2 65 J70…
Samsung Component Placer SM431 Service Manual
5-8
NO. LEVEL
PART NO. PART NAME Q'TY
TYPE Old No. Stock
Apply Reference
31 J70531406A SHUTTLE_WIDTH_SENSOR_BKT2 1
32 J70531407A SHUTTLE_WIDTH_FRAME 1
33 J70531408A SHUTTLE_PULLEY_COVER 1
34 J70531413A SHUTTLE_STOP_PLATE 2
35 J71531009A PULLEY_B_M 1
36 J71531173A SHUTTLE_BASE 1
37 J71531174A PULLEY10_P26-20-33F 2
P26-20-33F
38 J71531175A PULLEY6_P26-20-33F 1
P26-20-33F
39 J71531176A SHUTTLE_BELT_CLAMPING 1
40 J72531018A SHUTTLE_BUMPER 2
41 J66021090A TIMING_BELT-1545-3GT-20-UNITTA 1
1545-3GT-20
42 J31041014A STEP_MOTOR 1
2S56Q-01842SR2
43 J66021089A SHUTTLE_FLAT_BELT 1
44 J31081005A STEP_MOTOR-PBM565DXC26 1
PBM565DXC26
45 J66011104A BEARING-B608ZZ-MISUMI 6
B608ZZ
46 J66011101A BEARING-FL688ZZ-MISUMI 2
FL688ZZ
47 J60990101 SPACER-SMKB10-5-MISUMI 1
SMKB10-5
48 J31081004A MOTOR-PBM423DXC24-SANYO 1
PBM423DXC24
49 J90832839A PCB_SHUTTLE_SENSOR_CABLE_2-2 1
SM431_CS004
50 J3212002A SENSOR-EE-SX670A 1
EE-SX670A
51 J3212004A SENSOR-EE-SX672A 1
EE-SX672A
52 J66061005A CYLINDER 1
AQ2A12-30D
53 J66071075A LM_GUIDE 2
SBG15SL-2-K1-750L-N-SBC
54 J66191024A IDLER_ASSY_110 4
A-3_11.0
55 J70531380A LM_BLOCK_PLATE 2
56 J70531381A SHUTTLE_FRAME_RIB_L 1
57 J70531382A SHUTTLE_FRAME_RIB_R 1
58 J70531383A SHUTTLE_F_FRAME 1
59 J70531384A SHUTTLE_BELT_FIX_PLATE 1
60 J70531385A BELT_TENSION_SCREW 1
61 J70531386A PCB_GUIDE_EDGE_05T_L 1
Conveyor & BUT
5-9
NO. LEVEL
PART NO. PART NAME Q'TY
TYPE Old No. Stock
Apply Reference
62 J70531387A PCB_GUIDE_EDGE_05T_R 1
63 J70531388A SHUTTLE_BELT_UNDER_GUIDE 4
64 J70531389A PCB_GUIDE_EDGE_3_2T 2
65 J70531390A SHUTTLE_PULLEY_BASE 1
66 J70531392A SHUTTLE_PULLEY_SHAFT 1
67 J70531393A CABLE_VEYOR_BKT2 1
68 J70531394A CABLE_VEYOR_BKT1 1
69 J70531395A SHUTTLE_PCB_GUIDE_3_2T 1
70 J70531396A SHUTTLE_BELT_FIX_BKT 1
71 J70531397A SHUTTLE_CYLINDER_BKT 1
72 J70531398A SHUTTLE_WIDTH_SENSOR_BKT1 1
73 J70531399A SHUTTLE_PCB_SENSOR_BKT1 1
74 J70531400A HEX_BAR_M4_L32_5 4
75 J70531401A HEX_BAR_M4_L37 4
76 J70531402A SHUTTLE_HOME_SENSOR_BKT 1
77 J70531403A SHUTTLE_HOME_SENSOR_DOG 1
78 J70531404A MOVING_IDLER_SHAFT 2
79 J70531405A SHUTTLE_MOVING_MOTOR_BKT 1
80 J70531407A SHUTTLE_WIDTH_FRAME 1
81 J70531408A SHUTTLE_PULLEY_COVER 1
82 J70531410A SHUTTLE_PCB_SENSOR_BKT3 1
83 J70531412A LR_PCB_EXIT_SENSOR_BKT 1
84 J70531413A SHUTTLE_STOP_PLATE 2
85 J71531009A PULLEY_B_M 1
86 J71531173A SHUTTLE_BASE 1
87 J71531174A PULLEY10_P26-20-33F 2
88 J71531175A PULLEY6_P26-20-33F 1
89 J71531176A SHUTTLE_BELT_CLAMPING 1
90 J72531018A SHUTTLE_BUMPER 2
91 J66021090A TIMING_BELT-1545-3GT-20-UNITTA 1
1545-3GT-20
92 J31041014A STEP_MOTOR 1
2S56Q-01842SR2
Samsung Component Placer SM431 Service Manual
5-10
NO. LEVEL
PART NO. PART NAME Q'TY
TYPE Old No. Stock
Apply Reference
93 J70531495A WASHER-12-8-4 2
94 J66021089A SHUTTLE_FLAT_BELT 1
MAM-5P-873_6W
95 J31081005A STEP_MOTOR-PBM565DXC26 1
PBM565DXC26
96 J66011104A BEARING-B608ZZ-MISUMI 6
B608ZZ
97 J66011101A BEARING-FL688ZZ-MISUMI 2
FL688ZZ
98 J60990101 SPACER-SMKB10-5-MISUMI 1
SMKB10-5
99 J60490100 WASHER_WSSM10-5-3-MISUMI 4
WSSM10-5-3
100 J70531428A WORK_LM_BASE 2
101 J70531441A BUSH_TAIL_L_BKT1 2
102 J70531442A BUSH_TAIL_HOLDER 4
103 J70531443A BUSH_TAIL_L_BKT2 2
104 J72531002A BUSH_TAIL 4
105 J31081004A SERVO_MOTOR_PB 1
PBM423DXC24
106 J70531177A BUSHING 2
107 J6601126A BALL BEARING 4
108 J66021091A BELT-025-XL-240A-J-WOOSUNG 1
025-XL-240A-J
109 J66021092A BELT-MAM-5P-1304-6W-NAMIL 1
MAM-5P-1304-6W
110 J66021093A TIMING_BELT-174-3GT-9-UNITTA 1
174-3GT-9
111 J66071072A MINI_LM_GUIDE 3
SBMNS9-1-K1-40L-N
112 J66191024A IDLER_BEARING 5
113 J70531282A ADJUST_SHAFT 1
114 J70531284A CLAMP_SHAFT 2
115 J70531308A CLAMP_STOPPER_WASHER 2
116 J70531385A BELT_TENSION_SCREW 1
117 J70531386A PCB_GUIDE_EDGE_05T_L 2
118 J70531387A PCB_GUIDE_EDGE_05T_R 2
119 J70531389A PCB_GUIDE_EDGE_3_2T 4
120 J70531414A WORK_FIX_FRAME_BASE 2
121 J70531416A WORK_FIX_SUPPORT_R 1
122 J70531417A WORK_WIDTH_MOTOR_BKT 1
123 J70531418A WORK_CONVEYOR_MO_BKT 1
