Samsung Component Placer SM431 Service Manual 5-12 NO. LEVEL P ART NO. P ART NAME Q'TY TYPE Old No. Stock Apply Reference 155 J70531381A SHUTTLE_FRAME_RIB_L 1 156 J70531382A SHUTTLE_FRAME_RIB_R 1 157 J70531385A BEL …
Conveyor & BUT
5-11
NO. LEVEL
PART NO. PART NAME Q'TY
TYPE Old No. Stock
Apply Reference
124 J70531421A WORK_BELT_UNDER_GUIDE 2
125 J70531422A WORK_PCB_WIDTH_GUIDE1 1
126 J70531423A PCB_CLAMPING_GUIDE 1
127 J70531424A MINI_LM_BASE_PLATE 3
128 J70531425A CLAMPING_PLATE1 1
129 J70531426A CLAMPING_LIMIT_BKT 2
130 J70531427A WORK_FIX_FRAME 1
131 J71531009A PULLEY_B_M 1
132 J71531132A C_STOPPER_SPACER_DN 2
133 J71531177A WORK_WIDTH_MOTOR_PULLEY 1
134 J71531178A LEAD_SCREW_PULLEY2 1
135 J71531179A LEAD_SCREW_COM_PULLEY 1
136 J72531014A CLAMP_STOPPER_DN 2
137 J31041014A STEP_MOTOR 1
2S56Q-01842SR2
138 J70531415A WORK_FIX_SUPPORT_L 1
139 J70531419A BELT_TENSION_BKT 1
140 J70531420A BELT_TENSION_SHAFT 1
141 J66191007A LOCK_NUT 2
RN-8
142 J66141001B LEAD_SCREW 2
TTMR12+565L
143 J3212002A PHOTO SENSOR 1
EE-SX670A
144 J61071067A SPRING_WR12-20 2
WR12-20
145 J6601008A BALL BEARING 2
6000ZZ
146 J6049010 WASHER-WSSM10-6-2-MISUMI 2
WSSM10-6-2
147 J7253008A STOPPER 1
148 J66021092A BELT-MAM-5P-1304-6W-NAMIL 1
MAM-5P-1304-6W
149 J66071072A MINI_LM_GUIDE 3
SBMNS9-1-K1-40L-N
150 J66191024A IDLER_ASSY_110 5
A-3_11.0
151 J70531282A ADJUST_SHAFT 1
152 J70531284A CLAMP_SHAFT 2
153 J70531308A CLAMP_STOPPER_WASHER 2
154 J70531380A LM_BLOCK_PLATE 2
Samsung Component Placer SM431 Service Manual
5-12
NO. LEVEL
PART NO. PART NAME Q'TY
TYPE Old No. Stock
Apply Reference
155 J70531381A SHUTTLE_FRAME_RIB_L 1
156 J70531382A SHUTTLE_FRAME_RIB_R 1
157 J70531385A BELT_TENSION_SCREW 1
158 J70531386A PCB_GUIDE_EDGE_05T_L 2
159 J70531387A PCB_GUIDE_EDGE_05T_R 2
160 J70531389A PCB_GUIDE_EDGE_3_2T 4
161 J70531418A WORK_CONVEYOR_MO_BKT 1
162 J70531421A WORK_BELT_UNDER_GUIDE 2
163 J70531424A MINI_LM_BASE_PLATE 3
164 J70531426A CLAMPING_LIMIT_BKT 2
165 J70531431A WORK_MOVING_SUPPORT_L 1
166 J70531432A WORK_MOVING_FRAME 1
167 J70531433A WORK_MOVING_SUPPORT_R 1
168 J70531434A WORK_PCB_WIDTH_GUIDE2 1
169 J70531435A PCB_CLAMPING_GUIDE2 1
170 J70531438A CLAMPING_PLATE2 1
171 J70531439A WORK_MOVING_SENSOR_BKT1 1
172 J70531440A CABLE_VEYOR_BKT 1
173 J71531009A PULLEY_B_M 1
174 J71531132A C_STOPPER_SPACER_DN 2
175 J72531014A CLAMP_STOPPER_DN 2
176 J31041014A STEP_MOTOR 1
2S56Q-01842SR2
177 J61071067A SPRING_WR12-20 2
WR12-20
178 J66141001B LEAD_SCREW 2
TTMR12+565L
179 J7253008A STOPPER 1
180 J70531455A DUMP_BOX_SUPPORT 2
181 J70531456A CONVEYOR_CABLE_COVER 2
182 J70531457A CABLE_COVER_PLATE 2
183 J72531005B DUMP_BOX 2
184 J65041012A CABLE_VEYOR 2
HSP0180_2B_28R_21LINK
185 J67111034A FITTING 2
M-5HL-4
Conveyor & BUT
5-13
NO. LEVEL
PART NO. PART NAME Q'TY
TYPE Old No. Stock
Apply Reference
186 J90832836A PCB_SHUTTLE_SENSOR_CABLE_1-1 1
SM431_CS001
187 J90832837A PCB_SHUTTLE_SENSOR_CABLE_1-2 1
SM431_CS002
188 J67021005A SOLENOID_VALVE 5
DV1120-00-R3642-3
189 J6703007A THROTTLE VALVE(ELBOW) 1
JNC4-M5
190 J6711001A ELBOW FITTING 4
KQ2L04-M5/PL4-M5M/SQL04-M5
191 J6709004A REGULATOR 2
AR1000-M5BG
192 J90601049A SM431_AXIS_SENSOR_BOARD 1
1.6T, 2LAYER
193 J90832842A PCB_WORK_SENSOR_CABLE_2-1 1
SM431_CS007
194 J90832843A PCB_WORK_SENSOR_CABLE_2-2 1
SM431_CS008
195 J90832840A PCB_WORK_SENSOR_CABLE_1-1 1
SM431_CS005
196 J90832841A PCB_WORK_SENSOR_CABLE_1-2 1
SM431_CS006
