TX机台季度保养

www.asm-smt.com Preventive Maintenance Workflow 2 SIPLACE TX V2 Job Card Edition 07/2018 EN

www.asm-smt.com

Preventive Maintenance Workflow 2

SIPLACE TX V2

Job Card

Edition 07/2018 EN

All names identified by ® are registered trademarks of ASM Assembly Systems GmbH & Co. KG. The remaining trademarks in this publication may be trademarks whose use by third parties

for their own purposes could violate the rights of the owner.

We have reviewed the contents of this publication to ensure consistency with the hardware and software described. Since variance cannot be precluded entirely, we cannot guarantee full

consistency. However, the information in this publication is reviewed regularly and any necessary corrections are included in subsequent editions.

ASM Assembly Systems GmbH & Co. KG

Rupert-Mayer-Strasse 44

81379 Munich

Germany

Item no.: 00198586-01

www.asm-smt.com Printed by ASM Assembly Systems

www.asm-smt.com

Introduction

Safety Introduction

Equipment required for Workflow 2 Maintenance TX V2

1 Check the head status of the C&P20x to be maintained

2 Shut down, remove all tables (COT) and exchange all nozzles

3 Empty and clean the reject bin

4 Remove the C&P20x to be maintained

5 Return a maintained C&P20x

6 Clean the Z-Axis of the remaining C&P20x heads

7 Check and clean the magnetic surfaces and scale of X and Y-Axis

8 Clean the conveyor, lifting tables and gantry cables

9 Clean the stationary camera (CPP/ TH)

10 Clean the feeder modules and cut the tapes

11 Switch on the machine and return the tables (COT)

12 Calibrate the maintained C&P20x

13 Check the cover fans

14 Check the filter discs of all C&P20x

15 Check the nozzle status of all C&P heads

16 Endurance run

Table of Contents
