RS-1-Rev00 - 第66页
- - 31 . ACC ESS ORIE S PA RT CO MP ONE NT S 2 5 1 2 1 3 9 6 5 8 1 0 1 1 2 0 3 2 3 4 7 1 4 1 5 1 6 1 8 1 9 2 1 2 2 2 3 1 2 4 2 8 2 9 1 7 2 6 2 7
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 BT-0600400-EC URETHANE TUBE BLUE 6X4 12
2 BT-0800501-EA URETHANE TUBE BLUE 8X5 2.5
3 BT-0400251-EA URETHANE TUBE BLUE 4X2.5 3.05
4 WP-0841601-SC WASHER M8 2
5 PJ-3040800-02 ELBOW UNION 10
6 400-54839 SOFT NYLON 8 15.1
7 400-94700 AIR COMBINATION ASSY 1
8 400-63483 AIR COMBINATION (1)
9 BT-1000651-EB POLYURETHANE TUBE (1.7)
10 PJ-3081000-01 UNION Y (1)
11 SL-6061692-TN BOLT (4)
12 WP-0841601-SC WASHER M8 (4)
13 BT-1200801-EF TUBE (0.45)
14 BT-0400251-EA URETHANE TUBE BLUE 4X2.5 (0.05)
15 BT-1200801-EF TUBE (1)
16 401-47664 MANIFOLD_ASM 1
17 PJ-3040600-01 REDUCER ELBOW (3)
18 PX-9500070-00 PLUG (3)
19 PJ-3010600-03 REDUCER (3)
20 PJ-3091200-03 MANIFOLD (1)
21 PJ-0200000-03 PLUG ROUND 12 (1)
22 BT-0400251-EA URETHANE TUBE BLUE 4X2.5 2
23 SL-6042092-TN SCREW M4 L=20 2
24 PJ-3030800-01 UNION STRAIGHT 2
25 PJ-3010605-03 HALF UNION 1
26 BT-0600400-EC URETHANE TUBE BLUE 6X4 12.1
27 PJ-3030600-01 STRAIGHT UNION 1
28 401-47611 VACUUM_PUMP_AIR_ASM 1
29 BT-1000651-EB POLYURETHANE TUBE (0.3)
30 BT-1200801-EF TUBE (0.2)
31 PJ-3081200-02 UNION Y (1)
32 400-69259 DIFFERENT BORE UNION Y (2)
33 PJ-3010600-03 REDUCER (2)
34 PJ-3080600-07 UNION Y 5
35 PJ-0205000-02 PLUG 1
36 BT-1200801-EF TUBE 0.2
- -
31. ACCESSORIES PART COMPONENTS
2 5
1 2
1 3
9
6
5
8
1 0
1 1
2 0
3
2
3
4
7
1 4
1 5
1 6
1 8
1 9
2 1
2 2
2 3
1
2 4
2 8 2 9
1 7
2 6
2 7
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 CM-6005001-03 CHINA ROHS LABEL 10 L 1
2 400-77701 ACCESSORY CARTON CASE 1
3 E6953-861-B00 CONTENT LABEL 2
4 400-61008 CHINA_ROHS_RECYCLE_LABEL_A 1
5 PJ-0700000-01 SOCKET 1
6 161-21907 HOSE BAND 1
7 400-35043 3.7 DUMMY WAFER 1
8 J1080-000-000 BALL DRIVER 1
9 MDF-RX1001L0-9 DEFRIX OIL NO.1 (800CC) 1
10 J1067-000-000 OILER 1
11 400-32449 6459GREASE N 1
12 400-94361 NSL_GREASE 1
13 400-46643 CG2 GREASE 1
14 400-46528 ZM STOPPER 1
15 400-46644 ZM RUBBER 1
16 SL-6030892-TN SCREW M3 L=8 1
17 401-82877 ZA_FIXED_BRACKET 1
18 SL-6051092-TN SCREW M5 L=10 1
19 L132E-821-000 X STOPPER PLATE 1
20 E2424-725-000 STOPPER RUBBER R 1
21 SL-6061292-TN SCREW M6 L=12 2
22 401-06051 Y_FIX_BR_V2 2
23 SL-3061232-TN SCREW M6 L=12 8
24 400-87186 CAUTION_TAG 8
25 401-28431 BACK_UP_PIN_ASSY 12
26 401-82972 CHIP_BOX_RS1 1
27 401-82973 CHIP_BOX_CUSHION_RS1 1
28 400-81445 INFORMATION OF THE BATTERY DISPOSAL(JP) 1
29 400-89308 INFO OF THE BATTERY DISPOSAL(FOR BRAZIL) 1
