1 - 9 S tudent Guide SIPLACE HF/HF3 Edition 09/2005 1 1 MTC 2 9 Fig. 1 1.1 - 6 Information label below the main switch Fig. 1 1.1 - 7 Warning labels on the enclosures around the electric parts Fig. 1 1.1 - 8 Warning labe…
1 - 8
Student Guide SIPLACE HF/HF3
11 MTC 2 Edition 09/2005
8
Fig. 11.1 - 5 Location of the warning labels on the MTC 2 (left-hand side)
Key
1see Abb. 13.1 - 6 7see Abb. 13.1 - 12
2see Abb. 13.1 - 7 8see Abb. 13.1 - 13
3see Abb. 13.1 - 8 9see Abb. 13.1 - 14
4see Abb. 13.1 - 9 10see Abb. 13.1 - 15
5see Abb. 13.1 - 10 11 see Abb. 13.1 - 16
6see Abb. 13.1 - 11
8
4
2
2
4
5
5
5
10
9
3
1 - 9
Student Guide SIPLACE HF/HF3
Edition 09/2005 11 MTC 2
9
Fig. 11.1 - 6 Information label below the main switch
Fig. 11.1 - 7 Warning labels on the enclosures around the electric parts
Fig. 11.1 - 8 Warning label by the lifting axis motors
Read the Operating Instructions before
using the MTC for the first time.
Operation of the MTC is only permitted
when attached to a SIPLACE machine
and if the lifting axis guard is fitted.
Before detaching the MTC:
• Ensure that there is no set-up on the
MTC and move to transport position
• Push placement head away from the
feed area of the MTC
Transporting the MTC:
• Use a suitable pallet jack or fork lift
to transport the MTC long distances
• Set adjustable forks to the outer width of
the guide rails
• Stand the MTC on its rollers only when
not attached to the SIPLACE machine
Caution!
Disconnect the
power supply cord
before opening
housing!
Caution!
Operation is only
permittedwhenthe
guard is fitted.
1 - 10
Student Guide SIPLACE HF/HF3
11 MTC 2 Edition 09/2005
10
Fig. 11.1 - 9 Warning labels by the toothed belts of the lifting axis and feed axis
Fig. 11.1 - 10 Warning labels in the feeding area and the lifting frame area
Fig. 11.1 - 11 Warning labels in the refill area (behind the protective doors)
Fig. 11.1 - 12 Information label at the ground terminal
Fig. 11.1 - 13 Warning labels on the motor controller covers (below the enclosure)
