Edition 09/2005 SIPLACE HF/HF3
Appendix
14
20
Fig. 20.3 - 8 Menu function ’System control’ for ’SAT’ (in Expert mode only)
Important to set language and ’user level’
- All other settings keep on SIEMENS-default setting!!!
Important menus for the SIEMENS Service are the Download-menus in submenu ’connector’.
Therefore is a special CAN-HW and SW of a Service-Laptop is necessary.
5.0% 7,5% 10.0% 12,5% .
for power supply test of Axis contoller
System control
Back
Settings
User control
Display
Ports
Internal
Settings
Back
Load ...
Save ...
Load Settings
Back
Default
EEPROM
The settings have
been saved
User
Back
Language
User level
Boot and press ' '
Quit
configuration
machine
System control
Shutdown
About ...
Main menu
Choose language
Back
English
German
Change user
level
Back
Dummy *
* reboot for new user level
confirm Expert with return
Display
Back
Contrast
Screen saver
Ports
Back
CAN-Port
Set ASC Port
Internal
Back
Selftest
Dump EEPROM
Selftest
Back
Enable
Disable
Start
Set Tolerance
Please leave it on
Default
Expert*
CAN Ports
Change ASC port
Back
CAN IDs
Back
BIOS Bootstrap-Download
to axis controller
SAT< ->A36X
SAT<->PC
A36X<->PC
SW-Download to SAT
CAN Ports
Back
sending CT- IDs
sending Event -ID
receiving ID
CAN Menues for SAT
internal tests
SIPLACE HF/HF3 Edition 09/2005
Appendix
15
20.4 Software combinations SIPLACE HF
HF machines
Name of Machine modules kind to update SW Softwareversion 1 SC/
MC 504.02
Softwareversion 2
SC/MC 505.01
Softwareversion 3
SIPLACE PRO computer Installieren SIPLACE PRO 1.4 SIPLACE PRO 2.0
Station computer Installieren SC/MC 504.01/02 SC/MC 505.01
Machine controller Installieren SC/MC 504.01/02 SC/MC 505.01
SITEST in SC/MC integriert 504.01/02 505.01
Alle Achscontroller Download BIOS 3.02.00
Appl.1 3.01.01
Ap.2 X/Y/C&P 3.00.7E
Z
T
3.00.9F/D
T
3.00.A2
BIOS 3.02.00
Transportsteuerung Download BIOS 6.03.03
Applikation 6.03.23
BIOS 6.03.03
Applikation 6.05.04
MVS 340 Autom. Download 2231M 2231M
’8 Bit CAN processor’ on
C&P head adapter
Download BIOS 4.01.01
Applikation 4.06.04
BIOS 4.01.04
Applikation 4.06.04
Main board TWIN seg. 1/2 Download BIOS 1.01.00
Applikation 1.01.03
BIOS 1.02.00
Applikation 1.01.04
CAN proc. on head inter-
face (head board)
---
Vision board Download BIOS 5.01.0C
Appl. 1 5.01.02
BIOS 5.01.0C
Appl. 1 5.01.02
I/O controller Download BIOS 1.02.00
Appl. 1 1.02.00
BIOS 1.02.03
Appl. 1 1.FF.1C
Vision control board Download BIOS 5.01.0C
Appl. 1 5.01.02
BIOS 5.01.0C
Appl. 1 5.01.02
Comp. table controller Autom. Download BIOS 2.01.01
Applikation1 2.01.01
BIOS 2.01.01
Applikation 2.01.03
Tape cutter EPROM EPROM Tausch auf
Art.nr.03006411
update der Beta-ver-
sion’ 00309666-05’
update der Beta-ver-
sion’ 00309666-05’
Tape cutter Download BIOS 2.01.01
Appl.1 2.01.01
BIOS 2.01.01
Appl. 1 2.01.01
coplanarity module Download ---
MTC 2 CAN TOOL Down-
load
BIOS 1.92.02 BIOS 2.02.00
Appl.2.01.03
Tab. 20.4 - 1 SIPLACE HF
Edition 09/2005 SIPLACE HF/HF3
Appendix
16
other machines with SC/MC 505
machine modules S 25 HM / S27 HM Softwareversion 2 HS 50/60 Softwareversion 2
SIPLACE PROrech. SIPLACE PRO 2.0 SIPLACE PRO 2.0
Stationsrechner SC/MC 505.01 SC/MC 505.01
Maschinencontroller SC/MC 505.01 SC/MC 505.01
SITEST 505.01 505.01
Linienrechner nur bis ’SC/MC 503’ nur bis ’SC/MC 503’
Alle Achscontroller BIOS BIOS 1.02.07
Alle Achscontroller Applikation Applikation 4.1
MVS 340 2185 2272 M
Standard Kopfplatine
Modulare Kopfplatine 5.01 5.01
BE- Tisch 3.10 3.10
Gurtschneider EPROM 3.0 A 3.0A
MTC1 1.6 1.6
WPW Achsen 3.10 3.10
Tab. 20.4 - 2 SIPLACE S25 HM /S27 HM and HS 50 /HS60
