Model DECAN Series Company SAMSUNG TECHWIN Module 3.1 1 HEAD V ersion 01 Tit le 组装 HEAD AMP(F2) Page 3-1 1-19 Note * 按照编号顺序，连接电缆 * 拧紧系带
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.11 HEAD
Version
01
Title
组装HEAD AMP(F2)
Page
3-11-18
Note
Head AMP 布线
*从右侧向左侧连接电缆
*按照编号顺序，连接电缆
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.11 HEAD
Version
01
Title
组装HEAD AMP(F2)
Page
3-11-19
Note
*按照编号顺序，连接电缆
*拧紧系带
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.11 HEAD
Version
01
Title
组装HEAD AMP(F2)
Page
3-11-20
Note
*拧紧系带
*连接连接器及接地电缆
*将 H1H6-VAC、H7H10-VAC Cable 连接到 Flat Cable 后，拧紧到电路板
