TECHNICAL REFERENCE APPENDIX PREVENTIVE MAINTENANCE 3.116 Appendix to Micron Technical Manuals Chapter Issue 1 June 15 Figure 3-13 Squeegee Mechanism View on Front of Print Carriage Spindle Shafts Grease Nipples Drive Be…
TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
Chapter Issue 1 June 15 Appendix to Micron Technical Manuals 3.115
Figure 3-12 Screen Change Mechanism
Screen at Stop Sensor
Auto Drip Tray
Actuator Piston
Auto Drip Tray
Screen Stop
Actuator Arm Lever
TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
3.116 Appendix to Micron Technical Manuals Chapter Issue 1 June 15
Figure 3-13 Squeegee Mechanism
View on Front of Print Carriage
Spindle Shafts
Grease Nipples
Drive Belts
Leadscrew (rear squeegee
leadscrew not shown)
Supernut (rear squeegee
supernut not shown)
TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
Chapter Issue 1 June 15 Appendix to Micron Technical Manuals 3.117
Figure 3-14 Rail System
Horizontal Linear Bearing
Guide (in 2 positions)
Ballscrew
(in 2 positions)
Clatter Bar
(in 2 positions)
Vertical Linear Bearing
Guide (in 4 positions)
Plan View on Rail Drive System
View on Left Side of Machine
