0003-001 6-2 ㇱຠ⇟ภ ㇱ ຠ ฬ ஻ ⠨ PART No. PART NAME REMARKS CT-3291L CT-3292L CT-3291TL CT-3292TL 104 630 065 4738 DISK (REEL SOC KET ) 1 1 1 1 749R--01B-1 22 104 - 1 630 065 47 45 COL LAR 1 1 1 1 74 9R-- 01B- 123 104 -2 411 …

100%1 / 90
0003-001
6-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ஻ ⠨
PART No. PART NAME REMARKS
CT-3291L
CT-3292L
CT-3291TL
CT-3292TL
71 411 141 0307 NUT HEX 4 1 1 1 1 M4
72 630 039 3538 COLLAR 1 1 1 1 749R--01B-092
72 -1 630 039 2975 COLLAR 1 1 1 1 749R--01B-014
73 630 050 8260 LEVER(ASSY LEVER) 1 1
73 630 051 0935 LEVER(ASSY LEVER) 1 1
74 630 039 3262 ROLLER 1 1 1 1 749R--01B-060
75 630 039 3163 PIN,LOCATE 1 1 1 1 749R--01B-061
76 411 141 3902 WASHER V 3X7X0.5 1 1 1 1 FW3
77 411 141 2806 WASHER SPR 3 1 1 1 1 SW3
78 411 140 9905 NUT HEX 3 1 1 1 1 M3
79 630 039 3408 PIN,LOCATE 1 1 1 1 749R--01B-086
80 -1 411 141 4107 WASHER V 5X10X1 1 1 1 1 FW5
80 -2 411 141 6705 WASHER SPR 5 1 1 1 1 SW5
80 -3 411 141 0505 NUT HEX 5 1 1 1 1 M5
82 630 039 3552 COLLAR 1 1 1 1 749R--01B-094
83 630 039 3439 PLATE 1 1 1 1 749R--01B-088
84 630 010 6343 SEAL,RING 1 1 1 1 749R--01B-069
85 630 039 3194 PIN,LOCATE 1 1 1 1 749R--01B-049
86 -1 411 141 4107 WASHER V 5X10X1 1 1 1 1 FW5
86 -2 411 141 6705 WASHER SPR 5 1 1 1 1 SW5
86 -3 411 141 0505 NUT HEX 5 1 1 1 1 M5
88 630 050 8246 LEVER(ASSY RATCHT ARM) 1 1
88 630 051 0904 LEVER(ASSY RATCHT ARM) 1 1
89 630 039 3361 BRACKET 1 1 1 1 749R--01B-082
90 630 000 7626 BOLT,HEX-SCT 2 2 2 2 M4X10
91 411 141 4008 WASHER V 4X9X0.8 2 2 2 2 FW4
92 411 141 2905 WASHER SPR 4 2 2 2 2 SW4
93 411 141 0307 NUT HEX 4 2 2 2 2 M4
94 630 039 3019 LEVER(RATCHET CLICK) 2 2 2 2 749R--01B-016
95 630 010 6114 SPRING,TORSION 2 2 2 2 749R--01B-054
96 630 037 9327 PIN,LOCATE 2 2 2 2 749R--01B-053
97 411 141 0307 NUT HEX 4 1 1 1 1 M4
98 630 039 3477 HOOK 1 1 1 1 749R--01B-090
99 630 042 8346 SPRING,TENSION 1 1 749R--01B-089
99 630 042 9794 SPRING,TENSION 1 1 749S--01B-089
100 630 042 5857 SPRING,TENSION 1 749R--01B-056
100 630 042 9800 SPRING,TENSION 1 1 1 749S--01B-056
101 630 039 3132 DISK(REEL DRIVE) 1 1 1 1 749R--01B-042
102 630 010 6046 PIN,LOCATE 1 1 1 1 749R--01B-050
103 630 036 0967 BOLT(FLT HEX-SCT) 1 1 1 1 749R--01H-007
ᵈᗧ
NOTE
ᢙ㊂
Q'ty
⷗಴⇟
ภ
Key No.
0003-001
6-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ஻ ⠨
PART No. PART NAME REMARKS
CT-3291L
CT-3292L
CT-3291TL
CT-3292TL
104 630 065 4738 DISK(REEL SOCKET) 1 1 1 1 749R--01B-122
104 -1 630 065 4745 COLLAR 1 1 1 1 749R--01B-123
104 -2 411 140 6904 SCR FLT 2X6 4 4 4 4 M2X6 FLT
105 630 039 3309 SPRING,FLAT 1 1 1 1 749R--01B-068
106 630 037 3042 MACHINE SCREW 2 2 2 2 749R--01H-005
107 630 050 2275 BRACKET,LOCATE(ASSY BRKT) 1 1 1 1
108 630 010 8217 PULLEY 1 1 1 1 749R--01B-097
109 630 041 4905 COLLAR 1 1 1 1 749R--01B-114
110 411 000 9304 RING E 2 1 1 1 1 749R--01H-009
111 411 141 5807 WASHER F 3X6X0.5 2 2 2 2 FWS3
112 411 141 2806 WASHER SPR 3 2 2 2 2 SW3
113 630 000 7503 BOLT,HEX-SCT 2 2 2 2 M3X6
116 630 010 8378 GUIDE(TAPE) 1 1 1 1 749R--01B-096
117 411 119 1909 WASHER V 3X7X0.5 1 1 1 1 FW3 F
118 411 086 4408 WASHER SPR 3 1 1 1 1 SW3 F
119 411 041 8908 SCR PAN 3X6 1 1 1 1 M3X6 PAN
ᵈᗧ
NOTE
ᢙ㊂
Q'ty
⷗಴⇟
ภ
Key No.
