Page HANWHA 22 SME 12 mm SME Tape Feeder - Total NO. LEVEL P ART NO. P ART NAME Q 'TY TYPE OLD NO. Reference 28 S60060006A FHCS 4 S60060006A M4*8 29 S60010003A SHCS 2 S60010003A M4*10 30 J1301 154 FLA T W ASHER 1 S6…
Page
HANWHA
21
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
1 MC23-000035A SPROCKET SHAFT 1 S70000088A
2 MC23-000036A SPROCKET WASHER 2 S73000001A
3 FC18-000471A DROP GEAR WASHER 2 1 S70000089A
4 MC11-000432A SENSOR ADJUST CAM 1 S70000090A
5 FC18-000472A TAPE GUIDE FIX BOLT 1 S70000091A
6 J70660008C T_LINK1 SHAFT1 1
7 J70660001B T_LINK4 SHAFT1 1
8 FC38-000028A TOGGLE SPRING 1 S70000092A
9 FC15-000910A MAIN BOARD COVER 1 S72000044A
10 FC15-000251A DRIVING PART COVER 1 S70000093A
11 J7066079A REEL PLATE SHAFT 1
12 FC38-000027A TAPE GUIDE CUSHION SPRING 1 S70000095A
13 MC19-000328A VINYL GUIDE ROLLER SHAFT_16 3 S70000096A
14 J70652728A LOCKER LINK POST 1
15 J70652717A LOCKER SLOT PIN 1
16 J7066140A LOCKER SPRING 1
17 MC19-000333A TAPE GUIDE SHAFT_12 1 S70000097A
18 FC35-000008A VINYL GUIDE ROLLER_12 3 S72000045A
19 FC35-000072A VINYL ROLLER PROTECTOR 12 2 S71000041A
20 MC05-000022A TIMMING BELT 1 S66020001A
21 MC03-000392A BEARING 1 S66010001A
22 MC03-000393A BEARING 1 S66010002A
23 FC18-000474A BHCS 13 S60050001A
24 FC18-000475A BHCS 2 S60050002A
25 FC18-000476A BHCS 3 S60050003A
26 FC18-000477A BHCS 2 S60050005A
27 FC18-000479A FHCS 13 S60060004A
Page
HANWHA
22
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
28 S60060006A FHCS 4 S60060006A M4*8
29 S60010003A SHCS 2 S60010003A M4*10
30 J1301154 FLAT WASHER 1 S60420001A M3 (SUS)
31 J1301023 SNAP RING 1 S60710002A DIA3 (SUS)
32 AM03-001784A SPROCKET SENSOR BOARD ASSY 1 S91000018A
33 AM03-001785A SPROCKET SENSOR CABLE ASSY 1 S91000001A
Page
HANWHA
23
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
