SME_FEEDER_TRM(Ver3.9_CS19.01).pdf - 第61页
Page HANWHA 49 SME 16 mm SME Tape Feeder - Sub NO. LEVEL P ART NO. P ART NAME Q'TY TYPE OLD NO. Refer ence J J90651523A L OCKER ASSY 1 K AM03-001477A SME T APE GUIDE 16MM ASSY 1 S90000030A 1 FC38-000071A VINYL COVER…
Page
HANWHA
48
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
9 AM03-005003A VINYL SEPARATOR 1 1 S72000013A
10 J66011086A BALL_BEARING MF106ZZS 2 S66010005A
G FC35-000077A VINYL EXIT ROLLER ASSY 1 S90000018A
H AM03-005013A VINYL EXIT MOVING ASSY 1 S90000023A
Page
HANWHA
49
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
J J90651523A LOCKER ASSY 1
K AM03-001477A SME TAPE GUIDE 16MM ASSY 1 S90000030A
1 FC38-000071A VINYL COVER LEVER SPRING 1 S70000059A
2 FC18-000480A FHCS 2 S60060001A
L AM03-005021A VINYL ADT. ASSY 1 S90000036A
M AM03-005022A TAPE GUIDE SHUTTER ASSY 1 S90000038A
N AUX. ASSY 1
1 FC30-000800A AUX. PLATE 1 S71000021A
2 FC28-000327A LINK COVER 1 S72000033A
3 FC29-001089A GRIP NUT 1 S70000080A
4 J7265131A DAMPER 1
5 J7065802A DAMPER WASHER 1
6 J9065092A STOPPER ASSY 1
7-1 EP06-000087A MAIN BOARD(IT) 1 S91000002A
Page
HANWHA
50
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
8 AM03-001455A LIMIT SWITCH CABLE ASSY 1 S91000007
10 FC18-000479A FHCS 7 S60060004A
11 J6006201050 FHCS 2 S60060002A
12 FC18-000474A BHCS 2 S60050001A
13 FC18-000476A BHCS 2 S60050003A
14 J6025200050 NUT 2 S60250001A
16 J1301149 SNAP RING 2 S60710003A
O S90000056A FEEDER CLAMP ASSY 1
1 J90651524A CLAMP LEVER ASSY 1
2 AM07-006160A ASSY-ETC-CONTROL BOARD COVER S72000035A 1
3 AM03-014191A ASSY,ETC,IMS-CONTROL SWITCH COVER 1
4
5 AM03-001786A ASSY,TAPE FEEDER-SWITCH BOARD ASSY 1
6 AM03-001787A ASSY,TAPE FEEDER-SWITCH BOARD FLEX CABLE 1
7 AM03-014190A ASSY,ETC,IMS-FND GLASS 1
