Page HANWHA 55 SME 24 mm SME Tape Feeder - Total NO. LEVEL P ART NO. P ART NAME Q'TY TYPE OLD NO. Referen ce
Page
HANWHA
54
SME
24mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
28 FC18-000479A FHCS 13 S60060004A M3*6
29 J6006400838 FHCS 4 S60060006A M4*8
30 J6001401038 SHCS 2 S60010003A M4*10
31 J1301154 FLAT WASHER 1 S60420001A M3 (SUS)
32 J1301023 SNAP RING 1 S60710002A DIA3 (SUS)
33 AM03-001784A SPROCKET SENSOR BOARD ASSY 1 S91000018A
34 AM03-001785A SPROCKET SENSOR CABLE ASSY 1 S91000001A
Page
HANWHA
55
SME
24mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
Page
HANWHA
56
SME
24mm SME Tape Feeder
A
18
21
21
2
22
19
8
17
5
13
7
11
10
4
9
6
22
12
14
3
6
21
12
20
1
21
16
15
