Page HANWHA 62 SME 24 mm SME Tape Feeder - Sub NO. LEVEL P ART NO. P ART NAME Q'TY TYPE OLD NO . Reference 2 J70 650978C INST ALL GUIDE 1 3 FC18-000205A BTM LOC' PIN 1 4 J70 650948B LOCA TION FLANGE 1 5 FC18-00…
Page
HANWHA
61
SME
24mm SME Tape Feeder - Sub (6)
8
9
6
2
11
3
4
11
10
1
7
5
1
4
3
O
Page
HANWHA
62
SME
24mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
2 J70650978C INSTALL GUIDE 1
3 FC18-000205A BTM LOC' PIN 1
4 J70650948B LOCATION FLANGE 1
5 FC18-000204A FRONT GUIDE PIN 1
14 J66011014A BALL_BEARING_F605ZZ-STF100N F605ZZ 1 S66010003A
Page
HANWHA
63
SME
24mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
D EP08-000035A MOTOR ASSY 1 S90000011A
F AM03-001500AA VINYL DISCHARGE ASSY 1 S90000014
1 FC39-000730A DISCHARGE FRAME 1 S72000010A
2 MC19-000342A VINYL FIX ROLLER PULLEY 1 S72000011A PULLEY FLANGE included
