Page HANWHA 81 SME 32 , 44 , 56,72,88 mm SME Tape Feeder - Sub (6) NO. LEVEL P ART NO. P ART NAME Q'TY TYPE OLD NO . Reference 32mm 44mm 56mm 72mm 88mm 6 S60050006 A BHCS 1 1 1 1 1 D EP08-000035 A MOTOR ASSY 1 1 1 1…
Page
HANWHA
80
SME
32, 44, 56,72,88mm SME Tape Feeder - Sub (6)
NO. LEVEL PART NO. PART NAME
Q'TY
TYPE OLD NO. Reference
32mm 44mm 56mm 72mm 88mm
MC23-000039A SPROCKET SHAFT-56 0 0 1 0 0 S70000027A
MC19-000713A SPROCKET SHAFT-72 0 0 0 1 0 S70000239A
MC19-000807A SPROCKET SHAFT-88 0 0 0 0 1 S70000382A
19 S66010003A BEARING 1 1 1 1 1 S66010003A
B S90000007A SPROCKET ASSY 1 1 1 1 1 S90000008A
1 S70000029A SPROCKET 1 1 1 1 1
2 S72000002A SPROCKET GEAR 1 1 1 1 1
3 S70000030A GEAR FIX PIN 3 3 3 3 3
C AM03-001779A SPROCKET ASSY 1 1 1 1 1 S90000009A
Page
HANWHA
81
SME
32, 44, 56,72,88mm SME Tape Feeder - Sub (6)
NO. LEVEL PART NO. PART NAME
Q'TY
TYPE OLD NO. Reference
32mm 44mm 56mm 72mm 88mm
6 S60050006A BHCS 1 1 1 1 1
D EP08-000035A MOTOR ASSY 1 1 1 1 1 S90000011A
E AM03-001780A TENSION PULLEY ASSY 1 1 1 1 1 S90000012A
F AM03-001462A VINYL DISCHARGE ASSY-32 1 0 0 0 0 S90000013A
AM03-001500A VINYL DISCHARGE ASSY-44 0 1 0 0 0 S90000014
AM03-001487A VINYL DISCHARGE ASSY-56 0 0 1 0 0 S90000017A
AM03-011004A
VINYL DISCHARGE
ASSY-72
0001 0
S70000123A
AM01-001688A
VINYL DISCHARGE
ASSY-88
0000 1
S70000170A
1 FC39-000730A DISCHARGE FRAME 1 1 1 0 0 S72000010A
S71000073A DISCHARGE
FRAME-72
0001 1
2 MC19-000342A VINYL FIX ROLLER PULLEY 1 1 1 1 1 S72000011A
3 S70000037A SUPPORT CLAMP WASHER 1 1 1 1 1
4 S70000038A MOVING HANDLE SUPPORT 1 1 1 1 1
5 S70000003A VINYL MOVING SPRING SHAFT 2 1 1 1 1 1
6 S70000040A VINYL MOVING ROLLER SPRING 1 1 1 1 1
7 S70000004A IDLE FIX BOLT 1 1 1 1 1
9 AM03-005010A VINYL SEPARATOR 1_32 1 0 0 0 0 S72000015A
AM03-005011A VINYL SEPARATOR 1_44 0 1 0 0 0 S72000016A
AM03-005012A VINYL SEPARATOR 1_56 0 0 1 0 0 S72000017A
FC09-003460A
VINYL SEPARATOR 1_72 0 0 0 1 0
S72000085A
FC30-001897A
VINYL SEPARATOR 1_88 0 0 0 0 1
S72000135A
10 J66011086A BEARING 2 2 2 2 2 S66010005A
11 S60010002A SHCS 1 1 1 1 1
Page
HANWHA
82
SME
32, 44, 56,72,88mm SME Tape Feeder - Sub (6)
NO. LEVEL PART NO. PART NAME
Q'TY
TYPE OLD NO. Reference
32mm 44mm 56mm 72mm 88mm
12 S60420001A FLAT WASHER 1 1 1 1 1
13 S60010001A SHCS 2 2 2 2 2
G FC35-000079A VINYL EXIT ROLLER ASSY-32 1 0 0 0 0 S90000020A
FC35-000080A VINYL EXIT ROLLER ASSY-44 0 1 0 0 0 S90000021A
FC35-000081A VINYL EXIT ROLLER ASSY-56 0 0 1 0 0 S90000022A
AM03-011005A VINYL EXIT ROLLER ASSY-72 0 0 0 1 0 S90000124A
AM01-001689A VINYL EXIT ROLLER ASSY-88 0 0 0 0 0 S90000171A
1 S72000020A TORQUE LIMIT GEAR_32 1 0 0 0 0
S72000021A TORQUE LIMIT GEAR_44 0 1 0 0 0
S72000022A TORQUE LIMIT GEAR_56 0 0 1 0 0
S72000086A TORQUE LIMIT GEAR_72 0 0 0 1 0
S72000136A TORQUE LIMIT GEAR_88 0 0 0 0 1
2 S70000047A TORQUE LIMIT SHAFT_32 1 0 0 0 0
S70000049A TORQUE LIMIT SHAFT_44 0 1 0 0 0
S70000050A TORQUE LIMIT SHAFT_56 0 0 1 0 0
S70000243A TORQUE LIMIT SHAFT_72 0 0 0 1 0
S70000384A TORQUE LIMIT SHAFT_88 0 0 0 0 1
3 S70000043A TORQUE LIMIT SPRING 1 1 1 1 1
4 S70000044A TORQUE LIMIT SHAFT BOLT 1 1 1 1 1
H AM03-005018A VINYL EXIT MOVING ASSY_32 1 0 0 0 0 S90000025A
AM03-005019A VINYL EXIT MOVING ASSY_44 0 1 0 0 0 S90000026A
AM03-005020A VINYL EXIT MOVING ASSY_56 0 0 1 0 0 S90000027A
AM03-011006A VINYL EXIT MOVING ASSY-72 0 0 0 0 1 S90000125A
AM01-001690A VINYL EXIT MOVING ASSY-88 0 0 0 0 1 S90000172A
