8 Ⅲ .Connection and Use 3 .1 Connection 1. 5-pin s ocket: spare socket , 3.2.3 Fiv e -pin Socket I nstruction. 2. D B37port: s pare output port, refer to 3.3 I nstruction about DB37 s ocket. 3. DB9port: s pare output por…

100%1 / 41
7
3 Sy
ringe assy 9 Right start key
4
Y
Axis close loop stepper motor
+synchronous belt
10 Nozzle position correction device
5 J
ig baseplate 11 Teach pendant
6 L
eft start key
2
.3 Dimension
F
ront view Left view
T
op view 3D view
485
630
465
530
8
Ⅲ.Connection and Use
3
.1 Connection
1. 5-pin s
ocket: spare socket, 3.2.3 Five-pin Socket Instruction.
2. D
B37port: spare output port, refer to 3.3 Instruction about DB37 socket.
3. DB9port: spare output port, refer to 3.4 Instruction about DB9 socket.
4. 7-pin s
ocket: connect to dispensing controller, refer to 3.2.4 Seven-pin Socket Instruction.
5. 4-pin s
ocket: connect to key box, refer to 3.2.2 Four-pin Socket Instruction.
6. 5-pin socket: connect to nozzle position correction device, 3.2.3 Five-pin Socket Instruction.
3
.2 I/O Socket Instruction
3.2.1 Circuit Instruction of I/O Socket
1 2
3
4
5 6
9
3.2.2 Four-pin Socket Instruction
The fol
lowing list describes the function of 4-pin socket, it is connected to key box.
4-pin socket Pin NO.
Pin’s name
Instruction of pins Remark
1
Min4
Mai
n inputting 4 signal
It’s used to connect to “start/pause”
button.
2
GND
Powe
r supply “-” Power supply “-”
3
Min1
Main inputting 1 signal It is used to reset (ORG) signal
4
EMST
Em
ergency stop button
It is used to emergency stop
button.
N
OTE: * If the customers need special function, the input and output signal can be set again.
3.2.3 Five-pin Socket Instruction
The following list describes the function of 5-pin socket, it is a spare socket.
5-pin socket Pin NO.
Pin’s
name Instruction of pins Remark
1 24V
DC “+” power supply
2 G
ND Power supply “-”
3 Mi
n3 Main inputting 3 signal
Safety signal ,such as safety
light curtain \safety door etc.
4 Ein13 Exter
nal input 13 signal
5 Ein14 External input 14 signal
The following list describes the function of 5-pin socket, it’s used to light house.
