Measurement positions:
　　　　(5.05V±0.03V)
DC12V：between TP12V and TPGNG
　　　　(12.0V±1.0V)
DC24V：between TP24V and TP24G
　　　　(24.0V±0.3V)
Adjust the voltage. (if necessary)
Power supplies and Adjustment volumes (if necessary)
Direct Tray
Remark
15
To adjust the voltage, use each power
volume for DC5V, DC12V, and DC24V
in the box.
14
DC5V： between TP5V and TPGNG
Check the DC5V, DV12V, and DV24V
using the check terminals on the
NF24CX on the front side of the box.
16
Check the voltage.
13
Item
Tray
TP5V
TPGND
TP12V
TP24G
TP24V
DC5V power
Adjustment volume
DC12V power
DC24V power
EJM8A-E-SMA070201-A01-00
Page 7-2-1-5
AR connection
• Channel setting CHSW = 0
• Mode setting MODESW = 5
BR connection (Same as AR)
• Channel setting CHSW = 0
• Mode setting MODESW = 5
AR: Ring load #6
BR: Ring load #14
Key disk
Select the tray.
No problems as long as the version is
displayed on the Ring load information
screen.
Tray Direct Tray
Check the setting of NF24CX on the
front of the box.
19
Check the direct tray is set to "Use," checking the system parameter.
18
Check communication with the machine.
20
RemarkItem
Check the NF24CX setting.
17
CHSW
MODESW
AR
BR
EJM8A-E-SMA070201-A01-00
Page 7-2-1-6
(1) Select the tray.
(2) Jig setting
Put Nozzle 1003 on Head 3.
(3) Height teach
(4) Position teach
(5) Jig remove
Remove the Nozzle 1003 from Head 3.
Installation is finished.
Adjust the feeder-reel-support height if
necessary. When adjusting the tape-feeder-reel-
support height, adjust the height with the
three positions shown at left.
To adjust the height, use these two
collars. Insert the collar between the
plate and the adjusting bolt, and adjust
the height.
Tray Direct Tray
Item
Nozzle 1003
Remark
23
21
Install the machine covers.
Teach (in Serviceman mode)
Machine parameter/Machine parameter teach
See 7-2-2. Pickup Position Teaching.
22
24
Remove the cover from the side shown
at left, and put it on the front.
Remove the cover,
and put it on the front.
