Direct Tray • This section describes the procedures for positioning the magazine shutter stopper. Part Weight 7-2-3 Positioning the Magazine Shutter Stopper Tool Phillips screwdriver #2 Allen keys Level Teaching Assembly…
Tray Direct Tray
RemarkItem
(9) Press [Jig remove].
(10) Turn off (O) the servo switch.
(11) Open the safety cover.
(12) Remove the nozzle from the head.
(5) Close the safety cover.
(6) Turn on (I) the servo switch.
5
Remove the jig.
EJM8A-E-SMA070202-A01-00
Page 7-2-2-3
Direct Tray
• This section describes the procedures for positioning the magazine shutter stopper.
Part Weight
7-2-3 Positioning the Magazine Shutter Stopper
Tool
Phillips screwdriver #2
Allen keys
Level
Teaching
Assembly/AdjustmentRemoval/Disassembly
30
kgs.
30
Min.
Jig FM-1924
Min.Min. Min.
Tray
Jig
FM-1924
Caution
Danger
Warning
EJM8A-E-SMA070203-A01-00
Page 7-2-3-1
Jig: FM-1924
Level: (0.02mm/div.)
Jig: FM-1924
Put the jig on the extension section.
Check at the positions and .
Greasing (MP Grease 2S)
X and Y directions: Within 0.1 mm/m
2
3
Adjust the stopper pin.
Do not let grease go down.
RemarkItem
Level the extension section.
Direct TrayTray
Level the extension section with the jig
and the level.
Lock the stopper so that the shaft makes
a slight contact with the edge of the jig.
* Upper: Adjust at the NG discharge
section.
Lower: Adjust at the origin position.
After adjustment, apply grease to the
specified sections. Apply grease to the
stopper-touching sections. (To prevent
wear.)
1
Jig
Level
Jig: FM-1924
Stoppe
r
Spring
Cylinde
r
The wider side of the
eccentric pin is
positioned on this side.
Bolt
Greasing
EJM8A-E-SMA070203-A01-00
Page 7-2-3-2
