Put the palette table back on with the four Hexagon bolts. Return the extension-axis to the origin. Allen key 2 mm Phillips screwdriver #1 M3 6 pcs. Truss 6 pcs. Direct Tray Item Remark Tray 9 Allen key 4 mm Screw M5 4 p…

100%1 / 1093
Put the belt in place. Tension the belt at
the motor section. Loosen B. Tension it
in the order of A and B.
Check Tensions F1 and F2 with a
tension gauge.
Tray
After replacing the belt, tighten the belt-
clamp section.
section. Loosen A.
Allen key 4 mm
Screw M5 2 pcs.
Remark
Tension gauge
F1 48.5+/-3Hz
F2 231 +/- 17Hz
Loosen the belt tension at the motor
Replace the belt.
Allen key 2.5 mm
Screw M3 2 pcs.
Remove the belt-clamp section.
6
7
8
Item
Direct Tray
Allen key 2.5 mm
Screw M3 2 pcs.
5
Belt clamp
Extension-axis motor
Supply
section
A
F1=48.5Hz
A
B
F2=231Hz
Supply
section
Supply
section
EJM8A-E-SMA070208-A01-00
Page 7-2-8-3
Put the palette table back on with the
four Hexagon bolts.
Return the extension-axis to the origin.
Allen key 2 mm
Phillips screwdriver #1
M3 6 pcs.
Truss 6 pcs.
Direct Tray
Item Remark
Tray
9
Allen key 4 mm
Screw M5 4 pcs.
Turn on the power.
10
11
12
TP-axis
Screw M5×40
Allen key
EJM8A-E-SMA070208-A01-00
Page 7-2-8-4
Move the extension-axis towards you 382.5 mm.
Tray Direct Tray
Remark
How to position the jig. (right picture)
Jig: FM-1924
turned by hand. Remove the jig.
Torque wrench 9.8N•m
Allen key 4 mm
Screw M5 4 pcs.
Allen key 2.5 mm
Screw M3 2 pcs.
After tightening, the bearing should be
13
Position the bearing with the jig.
14
Tighten the power locks at the motor section
with a torque wrench. TIghtening torque:
9.8N•m
16
Item
15
The dowel pin of the jig should be inside the LM, and
the hollow of the rear of the jig should on the LM.
Position the dog slit at the extension
position. Inch the axis with a pitch of 0.1
mm.
436.5
A=382.5mm
Origin position
E
C
D
(392.5)
6
F
Magazine
(2)
(51)
B=9
Supply
section
Magazine side
(0.5 mm)
Lift side
(1.0 mm)
Optical-axis sensor
Extension position PH sensor
PH632( 32)
　Dog
Light through: ON
Light blocked: OFF
Light blocked at mechanical stopper on negative direction.
Supply section
EJM8A-E-SMA070208-A01-00
Page 7-2-8-5
