8 Control Hardw are Thi s chapte r desc rib es t he cont rol ha rd ware . EJM 8A-E- SMAA-0000 Conf ident ial
1. Tray Control (NF24CB) Board Setting
zRing channel setting
• Ring channel auto judgment: Common to Stages A and B
MODESW: 5
SWCH: 0
zOthers (Jumpers and switches) The same setting as before
JP1: OPEN JP2: OPEN JP3: SHORT
SW1: to 422 JP232C: SHORT
7-2-16 Tray Control (NF24CB) Board Setting
Direct TrayTray
SWCH
JP 1 - 3
JP232C
MODESW
SW1
EJM8A-E-SMA070216-A01-00
Page 7-2-16-1
