3 Jig & T oo l This chapte r desc ribes j igs and t ools. EJM 8A-E- SMAA-0000 Conf ident ial
ST40-20
Ｎｏ
Attach Detach
1 X-axis table locking metal fitting Metal fitting×1
M4-10 boltｰ4
2 Z-axis table locking metal fitting Metal fitting x 2
M3-8 bolt - E382x2
3 Lifter axis locking metal fitting Metal fitting
M5-12 bolt×4
4 Pallet drawing unit locking metal fitting Metal fitting
M3 -10 bolt x 1
5 Conveyor locking metal fitting Metal fitting x 1
M4 - 10 bolt x 3
Name of metal fittings Parts/Bolt size/Qty
Installation Machine Installation
EJM8A-E-SMA020104-A01-00
Page 2-1-4-2
3 Jig & Tool
This chapter describes jigs and tools.
EJM8A-E-SMAA-0000
Confidential
