NO Jig How to use
33
Adm. No.
FM-1067
Name
M/C models
CM402
NO Jig How to use
34
Adm. No.
FM-1069
Name
Spline
holding jig
M/C models
CM402-L
NO Jig How to use
35
Adm. No.
FM-1074
Name
Board jig
M/C models
CM202-D/DH
CM301/402
NO Jig How to use
36
Adm. No.
FM-1075
Name
M/C models
CM402-L
Nozzle changer
shutter positioning jig
Nozzle
angle jig
Jigs and Tools Jigs and Inspection Devices
EJM8A-E-SMA030101-A01-00
Page　3-1-1-11
NO Jig How to use
37
Adm. No.
FM-1100
Name
M/C models
CM402-L
NO Jig How to use
38
Adm. No.
FM-1112
Name
M/C models
CM402-L
NO Jig How to use
39
Adm. No.
FM-1117
Name
M/C models
CM402-L
NO Jig How to use
40
Adm. No.
FM-1122
Name
M/C models
CM402-L
Jigs and Tools Jigs and Inspection Devices
Head camera
height board
jig
Nozzle changer
position check
jig
Camera
reflector
centering jig
Z-plate linear-rail
parallelism jig
EJM8A-E-SMA030101-A01-00
Page　3-1-1-12
NO Jig How to use
41
Adm. No.
FM-1126
Name
Feeder table
raising jig
M/C models
CM402-L
NO Jig How to use
42
Adm. No.
FM-1133
Name
M/C models
CM402-L
NO Jig How to use
43
Adm. No.
FM-1134
Name
M/C models
CM301
CM402-L
NO Jig How to use
44
Adm. No.
FM-1136
Name
M/C models
CM301
CM402-L
Jigs and Tools Jigs and Inspection Devices
Loa
d
measure-
ment device
LED lamp
teaching jig
Z-axis motor
alignment jig
EJM8A-E-SMA030101-A01-00
Page　3-1-1-13
