CM602-L
Service Manual
16
Beware of the guide for collectively changing truck.
You may stumble over the guide for collectively changing truck and get injured when
operating without the collectively changing truck.
We recommend that you should paste yellow and black tapes for danger indication onto the floor where is
120 mm or more away from around the machine, in order to draw a distinct line between the operator area
and the maintenance area (see Fig. 1 and Fig. 2).
We recommend that you should keep away from the most protrudent part (the guide for collectively
changing truck) of the machine by 120 mm or more (outside of the area with yellow and black stripes), as
shown in Fig. 2.
Fig. 1 Fig. 2 (Top view)
M108C
EJM8A-E-XXA00-A03-00
120 mm
120 mm
Operator area
Maintenance area
4Z4C-827E
EJM4A-005E
Black
Yellow
Guide for collectively
changing truck
Guide for collectively
chan
g
in
g
truck
CM602-L
Service Manual
17
Do not peer into the board eject area.
Ejected boards can strike and injure eyes.
In case you use the machine on a standalone basis, be careful of the receipt of unloaded boards. Normally
we cannot look inside the opening for unloading because the machine is installed close to the next machine
in whole line. If, however, you use it on a standalone basis, doing so is possible. We recommend you to add
a buffer stocker to the unloading side.
Board flow direction
Machine’s side view
PW0106M1
Do not look inside.
EJM8A-E-XXA00-A03-00
EJM4A-AB01
4Z4C-828E
Do not look inside.
CM602-L
Service Manual
18
Do not put your hands in the openings between feeders installed.
Your hands may be injured by the moving parts in the machine.
We recommend installing all feeders so that you will not accidentally put your hands into the machine.
M114
Extension-conveyor cover (Option)
Do not work with the conveyor cover opened.
Your hands may be injured by the moving parts in the machine.
Cover
M115
EJM4A-AE01
E64C-010E
EJM8A-E-XXA00-A03-00
EJM4A-AC01
