CM602all_EJM8AESM_Service Manual - 第171页
13 Put back the feeder cover. Tools and Specifications Phillips screwdriver #2 Screw M4 2 pcs. 12 Remove the cutter chute cover. Item Maintenance Adjustment Main Body Beam Allen key 3 mm Screw M4 3 pcs. Tools and Specifi…
Do not tighten excessively;
it is all right just to lock the
bracket.
Tighten the adjusting bolt
Maintenance Adjustment Main Body Beam
9
Wrench 7 mm
Nut 7 mm
holding nut.
Remarks
Tools and Specifications
12
Once the adjustment has been
completed, carry out "Z teach."
Tools and Specifications
Tools and Specifications
Iron plate
Magnetic stand
Dial gauge
Allen key 3 mm
Screw M4-15 1 pc.
Magnetic stand
Dial gauge
For details, refer to
"Section 4-3-11 Lead
Checker"
11
Check the levelness of the top
Tools and Specifications
of the lead checker.
Place an iron plate and the dial
Item
10
gauge onto the head.
Holding bracket
EJM8A-E-SMA040109-A01-00
Page 4-1-9-4
13
Put back the feeder cover.
Tools and Specifications
Phillips screwdriver #2
Screw M4 2 pcs.
12
Remove the cutter chute cover.
Item
Maintenance Adjustment Main Body Beam
Allen key 3 mm
Screw M4 3 pcs.
Tools and Specifications
Remarks
EJM8A-E-SMA040109-A01-00
Page 4-1-9-5
Maintenance Adjustment Main Body Beam
4-1-10 Lift-axis Stroke Adjustment
EJM8A-E-SMA040110-A01-00
Page4-1-10-1
