CM602-L
Service Manual
18
Do not put your hands in the openings between feeders installed.
Your hands may be injured by the moving parts in the machine.
We recommend installing all feeders so that you will not accidentally put your hands into the machine.
M114
Extension-conveyor cover (Option)
Do not work with the conveyor cover opened.
Your hands may be injured by the moving parts in the machine.
Cover
M115
EJM4A-AE01
E64C-010E
EJM8A-E-XXA00-A03-00
EJM4A-AC01
CM602-L
Service Manual
19
In maintenance, be careful not to receive an electric shock.
Even if the power supply switch is OFF in maintenance, the power is still supplied as far
as its primary line; therefore, you may receive an electric shock.
M111B
EJM8A-E-XXA00-A03-00
EJM4A-AA01
L1
L2
L3
PE
4Z4C-825E
