Points (1) to (12). 12 Re-check the levelness. Employing (8) as reference, measure All sections except board clamp section: Levelness: ±0.1 ㎜ Board clamp section: Levelness: within ±0.02 mm Reference height: 169.35±0.1 ㎜…

100%1 / 1093
Points (1) to (12).
Allen key 3 mm
Magic marker
Screw M4 2 pcs.
The fixed-conveyor eccentric pin is
placed at the back of the sensor.
8
Main Body Beam
Item Remarks
5
Maintenance Adjustment
All sections except board clamp
section:
Levelness: ±0.1 mm
Board clamp section:
Levelness:
within ±0.02 mm
Reference height:
169.35±0.1 mm
(when surface table is used)
Dial gauge, Magnetic stand
7
Allen key 4 mm
Screw M5 4 pcs.
6
Conveyor Height Adjustment
Loosen the eccentric pin holding nut.
Box wrench 7 mm
Employing (8) as reference, measure
Loosen the conveyor holding bolts.
Check the levelness of the fixed clamp rail.
Fixed conveyor
(Board detection)
Fixed conveyor
(Stopper section)
Fixed conveyors Movable conveyors
Fixed conveyor
Movable conveyor
(Left and Right: symmetric)
11
4
2
8
9
53
10 12
1
7
6
EJM8A-E-SMA040114-A01-00
Page　4-1-14-3
Points (1) to (12).
12
Re-check the levelness.
Employing (8) as reference, measure
All sections except board clamp
section:
Levelness: ±0.1㎜
Board clamp section:
Levelness:
within ±0.02 mm
Reference height:
169.35±0.1㎜
Dial gauge, Magnetic stand
11
Tighten the eccentric pin nut.
Box wrench 7 mm
10
Tighten the conveyor holding bolts.
Allen key 4 mm
Screw M5 4 pcs.
Item Remarks
9
Phillips screwdriver #2
Eccentric pin
To adjust the height, rotate the eccentric pin.
Maintenance Adjustment Main Body Beam
Fixed conveyors Movable conveyors
11
4
2
8
9
53
10 12
1
7
6
To raise or lower the
conveyors, rotate the
ti i
169.35+/-0.1mm
Movable conveyor
(
Left and Ri
g
ht: s
y
mmetric
)
Fixed conveyors
Movable conveyor
(Left and Right: symmetric)
EJM8A-E-SMA040114-A01-00
Page　4-1-14-4
Maintenance Adjustment Main Body Beam
Item Remarks
15
Phillips screwdriver #2
Allen key 3 mm
Screw M4 2 pcs.
M4x10 3 pcs.
Put the feeder cover and the chute back on.
14
Remove the iron plate from the head.
Allen key 3 mm
Screw M4 1 pc.
13
Put the transfer conveyor belt back on.
High-speed
head
Multi-purpose
head
EJM8A-E-SMA040114-A01-00
Page　4-1-14-5
