Maintenance Adjustment Light Transfer-Head Assembly (3 nozzles) Tools Ruler 500 mm Jig None 4-3-1 Conveyor-Width-Adjusting Axis Origin Offset This section describes the procedures for determining the offset for the origi…
(over the NG box).
The head of the selected stage returns
to the origin.
Maintenance Adjustment Transfer Head Assembly(8 nozzles)
Item
simultaneously.
Press the "Return" key.
Press [Unlock] and [Run]
simultaneously.
7
6
5
Press [Unlock] and [Jig remove]
The head moves to the jig setting positio
n
Remarks
Remove the jig from
Nozzle Position 3.
EJM8A-E-SMA040210-A01-00
Page 4-2-10-3
Maintenance Adjustment Light Transfer-Head Assembly (3 nozzles)
Tools
Ruler 500 mm
Jig
None
4-3-1 Conveyor-Width-Adjusting Axis Origin Offset
This section describes the procedures for determining the offset for the origin of the conveyor-width adjusting axis.
Light Transfer-Head Assembly (3 nozzles)
4-3
Assembly
A
d
j
ustment
min.
Teaching
3min.
Total Time Weight of
Part
Removal
Disassembl
y
min.
3min.
kgs
Caution
Dange
r
Warning
EJM8A-E-SMA040301-A01-00
Page 4-3-1-1
Maintenance Adjustment Light Transfer-Head Assembly (3 nozzles)
Remarks
Press [PCB recog camera Xyaxis OriginOffset].
Select the desired stage.
Press [Unlock] and [Return to origin] simultaneously.
The width adjusting axis returns to the
origin.
Press [Unlock] and one of the arrow keys - [
↑] or [↓] - simultaneously.
Moving the width adjusting axis and
measuring the width of the conveyor with
a ruler, adjust the width to 460.5 mm.
Each time the [Key rsps] key is pressed,
the amount by which the axis moves is
changed from 0.01 mm to 0.1 mm and 1
mm.
Specifications:
460.0 mm + 0.5mm to
0.7mm
(460.5mm to 460.7mm)
2
3
4
1
Item
EJM8A-E-SMA040301-A01-00
Page 4-3-1-2
