For details, see Section 4-3-4. "Chip Recognition Camera Theta Axis Origin Offset" 10 11 12 To warm up the machine, press Fit three 1005 nozzles onto each stage: Nozzle 1005 6 pcs. 9 Select the desired stage. […

100%1 / 1093
feeder table, tightening the black screws.
Td4Z4C-a-SHA :Type A High-speed head shadow teaching
Td4Z4C-a-DIR :Type A High-speed head direct teaching
Td4Z4C-b-45D : Type B Multi-purpose head 45°teaching
Td4Z4C-b-90D : Type B Multi-purpose head 90°teaching
Td4Z4C-c-S45
: Type C High-speed shadow teaching, Multi-purpose head 45°teachin
g
Td4Z4C-c-D90
: Type C High-speed direct teaching, Multi-purpose head 90°teaching
* Type A: High-speed heads at Stages A and B
* Type B: Multi-purpose heads at Stages A and B
* Type C: High-speed head at Stage A, Multi-purpose head at Stage B
* To prevent the glass QFP jigs from
being damaged when discharged into
the NG box.
6
7
8
Place cloth in the NG box.
Data type
Load data.
REMARKS
Maintenance Adjustment
5
front and rear stages. Fix the jigs on the
Clean the QFP jigs. Place
them onto Nos. 4 to 18 of
the QFP-jig supplying jig.
Remove the feeder cover.
Place the QFP-jig supplying jig on the
Light Transfer-Head Assembly(3 nozzles)
ITEM
4 18
Slot 5 Slot 26
FrontRear
EJM8A-E-SMA040307-A01-00
Page　4-3-7-4
For details, see Section 4-3-4. "Chip
Recognition Camera Theta Axis Origin Offset"
10
11
12
To warm up the machine, press
Fit three 1005 nozzles onto each stage:
Nozzle 1005 6 pcs.
9
Select the desired stage.
[Production].
Re-teach rotation center position to
all heads. front and rear.
Adjust the width of the conveyors manually.
Maintenance Adjustment Light Transfer-Head Assembly(3 nozzles)
ITEM REMARKS
Place the light box.
Be careful of tape position.
①
②
③
Stopper
Light Box
Middle position
Do not place
tape here!
Fixed tape
Position the light box close to the stopper.
EJM8A-E-SMA040307-A01-00
Page　4-3-7-5
Press the "Return" key. Press [Yes].
keys
15
14
ITEM
Maintenance Adjustment Light Transfer-Head Assembly(3 nozzles)
16
Pickup and recognition are
suspended and test run
starts.
Warm up the machine for
approximately 10 minutes
and press [Cycle stop] to
stop the machine.
Press [OK].
Press [Yes].
Press the "Unlock" and the "Start" Test Run screen
REMARKS
13
Press [Warmup operation].
Press [ESC].
EJM8A-E-SMA040307-A01-00
Page　4-3-7-6
